2G91 | pdb_00002g91

Crystal Structure Analysis of the an RNA nonamer r(GGUGCGC)d(BrC)r(C)

PDB DOI: https://doi.org/10.2210/pdb2G91/pdb
NAKB: 2G91

Classification: RNA
Mutation(s): No

Deposited: 2006-03-04 Released: 2007-04-03
Deposition Author(s): Shi, K., Pan, B., Sundaralingam, M.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free:
0.229 (Depositor)
R-Value Work:
0.187 (Depositor)
R-Value Observed:
0.190 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

Crystal Structure of an RNA nonamer r(GGUGCGC)d(BrC)r(C) at 1.5 A resolution

Shi, K., Pan, B., Sundaralingam, M.

To be published.

Macromolecule Content

Total Structure Weight: 5.9 kDa
Atom Count: 448
Modeled Residue Count: 17
Deposited Residue Count: 18
Unique nucleic acid chains: 1

Macromolecules

Find similar nucleic acids by: Sequence | 3D Structure

Entity ID: 1
Molecule	Chains	Length	Organism	Image
5'-R(GPGPUPGPCPGPCP(CBR)P*C-3'	A, B	9	N/A
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MG Query on MG Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth B]	C [auth A], D [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free: 0.229 (Depositor)
R-Value Work: 0.187 (Depositor)
R-Value Observed: 0.190 (Depositor)

Space Group: H 3 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 44.83	α = 90
b = 44.83	β = 90
c = 125.91	γ = 120

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
X-PLOR	model building
CNS	refinement
X-PLOR	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2007-04-03

Deposition Author(s):

Sundaralingam, M.

Revision History (Full details and data files)

Version 1.0: 2007-04-03
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Version format compliance
Version 1.3: 2024-02-14
Changes: Data collection, Database references, Derived calculations
