2G0Z

Photolyzed CO L29F Myoglobin: 1ns


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.070
  • R-Value Work: 0.058
  • R-Value Observed: 0.058

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 2.2 of the entry. See complete history


Literature

Time-dependent atomic coordinates for the dissociation of carbon monoxide from myoglobin.

Aranda, R.Levin, E.J.Schotte, F.Anfinrud, P.A.Phillips Jr., G.N.

(2006) Acta Crystallogr D Biol Crystallogr 62: 776-783

  • DOI: https://doi.org/10.1107/S0907444906017318
  • Primary Citation of Related Structures:
    2G0R, 2G0S, 2G0V, 2G0X, 2G0Z, 2G10, 2G11, 2G12, 2G14

  • PubMed Abstract:

    Picosecond time-resolved crystallography was used to follow the dissociation of carbon monoxide from the heme pocket of a mutant sperm whale myoglobin and the resultant conformational changes. Electron-density maps have previously been created at various time points and used to describe amino-acid side-chain and carbon monoxide movements. In this work, difference refinement was employed to generate atomic coordinates at each time point in order to create a more explicit quantitative representation of the photo-dissociation process. After photolysis the carbon monoxide moves to a docking site, causing rearrangements in the heme-pocket residues, the coordinate changes of which can be plotted as a function of time. These include rotations of the heme-pocket phenylalanine concomitant with movement of the distal histidine toward the solvent, potentially allowing carbon monoxide movement in and out of the protein and proximal displacement of the heme iron. The degree of relaxation toward the intermediate and deoxy states was probed by analysis of the coordinate movements in the time-resolved models, revealing a non-linear progression toward the unbound state with coordinate movements that begin in the heme-pocket area and then propagate throughout the rest of the protein.


  • Organizational Affiliation

    Department of Biomolecular Chemistry, University of Wisconsin, Madison, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Myoglobin154Physeter catodonMutation(s): 2
Gene Names: MB
UniProt
Find proteins for P02185 (Physeter macrocephalus)
Explore P02185
Go to UniProtKB:  P02185
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02185
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.070
  • R-Value Work: 0.058
  • R-Value Observed: 0.058
  • Space Group: P 6
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 91.2α = 90
b = 91.2β = 90
c = 45.87γ = 120
Software Package:
Software NamePurpose
CNSrefinement
LAUEGENdata scaling
PROWdata scaling
LSCALEdata scaling
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-07-04
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2015-01-14
    Changes: Database references
  • Version 1.4: 2017-10-18
    Changes: Refinement description
  • Version 2.0: 2018-02-28
    Changes: Advisory, Atomic model
  • Version 2.1: 2021-10-20
    Changes: Database references, Derived calculations
  • Version 2.2: 2023-08-30
    Changes: Data collection, Refinement description
