2FQP | pdb_00002fqp

Crystal structure of a cupin domain (bp2299) from bordetella pertussis tohama i at 1.80 A resolution

• PDB DOI: https://doi.org/10.2210/pdb2FQP/pdb

• Classification: METAL BINDING PROTEIN
• Organism(s): Bordetella pertussis Tohama I
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2006-01-18 Released: 2006-05-16
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:
  0.202 (Depositor), 0.210 (DCC)
• R-Value Work:
  0.154 (Depositor), 0.160 (DCC)
• R-Value Observed:
  0.156 (Depositor)

Literature

Crystal structure of (np_880937.1) from BORDETELLA PERTUSSIS at 1.80 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Biological Assembly 3

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 3 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 44.45 kDa
• Atom Count: 3,310
• Modeled Residue Count: 378
• Deposited Residue Count: 388
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
hypothetical protein BP2299	A, B, C, D	97	Bordetella pertussis Tohama I	Mutation(s): 3  Gene Names: np_880937.1
UniProt
Find proteins for Q7VWF8 (Bordetella pertussis (strain Tohama I / ATCC BAA-589 / NCTC 13251)) Explore Q7VWF8  Go to UniProtKB:  Q7VWF8

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
1PE	K [auth C]	PENTAETHYLENE GLYCOL C10 H22 O6 JLFNLZLINWHATN-UHFFFAOYSA-N
ZN	E [auth A], G [auth B], I [auth C], L [auth D]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
ACT	F [auth A], H [auth B], J [auth C], M [auth D]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:  0.202 (Depositor), 0.210 (DCC)
• R-Value Work:  0.154 (Depositor), 0.160 (DCC)
• R-Value Observed: 0.156 (Depositor)

Diffraction Data: https://doi.org/10.18430/M32FQP

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 35.919	α = 90
b = 92.651	β = 106.4
c = 53.058	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SCALA	data scaling
PDB_EXTRACT	data extraction
SOLVE	phasing
SHARP	phasing
DM	phasing
RESOLVE	phasing
MOSFLM	data reduction
CCP4	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2006-05-16
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2006-05-16
  Type: Initial release

• Version 1.1: 2008-05-01
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.3: 2023-01-25
  Changes: Advisory, Database references, Derived calculations
• Version 1.4: 2024-11-13
  Changes: Data collection, Refinement description, Structure summary
