2F8S

Crystal structure of Aa-Ago with externally-bound siRNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3 Å
  • R-Value Free: 0.307
  • R-Value Work: 0.212

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

A Potential Protein-RNA Recognition Event along the RISC-Loading Pathway from the Structure of A. aeolicus Argonaute with Externally Bound siRNA.

Yuan, Y.R.Pei, Y.Chen, H.Y.Tuschl, T.Patel, D.J.

(2006) Structure 14: 1557-1565

  • DOI: 10.1016/j.str.2006.08.009
  • Primary Citation of Related Structures:  2F8T

  • PubMed Abstract:
  • Argonaute proteins are key components of the RNA-induced silencing complex (RISC). They provide both architectural and catalytic functionalities associated with small interfering RNA (siRNA) guide strand recognition and subsequent guide strand-mediat ...

    Argonaute proteins are key components of the RNA-induced silencing complex (RISC). They provide both architectural and catalytic functionalities associated with small interfering RNA (siRNA) guide strand recognition and subsequent guide strand-mediated cleavage of complementary mRNAs. We report on the 3.0 A crystal structures of 22-mer and 26-mer siRNAs bound to Aquifex aeolicus Argonaute (Aa-Ago), where one 2 nt 3' overhang of the siRNA inserts into a cavity positioned on the outer surface of the PAZ-containing lobe of the bilobal Aa-Ago architecture. The first overhang nucleotide stacks over a tyrosine ring, while the second overhang nucleotide, together with the intervening sugar-phosphate backbone, inserts into a preformed surface cavity. Photochemical crosslinking studies on Aa-Ago with 5-iodoU-labeled single-stranded siRNA and siRNA duplex provide support for this externally bound siRNA-Aa-Ago complex. The structure and biochemical data together provide insights into a protein-RNA recognition event potentially associated with the RISC-loading pathway.


    Organizational Affiliation

    Structural Biology Program, Memorial Sloan-Kettering Cancer Center, New York, New York 10021, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Argonaute protein
A, B
706Aquifex aeolicus (strain VF5)N/A
Find proteins for O67434 (Aquifex aeolicus (strain VF5))
Go to UniProtKB:  O67434
Entity ID: 1
MoleculeChainsLengthOrganism
5'-R(P*AP*GP*AP*CP*AP*GP*CP*AP*UP*AP*UP*AP*UP*GP*CP*UP*GP*UP*CP*UP*UP*U)-3'C,D22N/A
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3 Å
  • R-Value Free: 0.307
  • R-Value Work: 0.212
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 79.697α = 90.00
b = 117.516β = 99.12
c = 98.620γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data reduction
REFMACrefinement
SCALEPACKdata scaling
MLPHAREphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2006-10-31
    Type: Initial release
  • Version 1.1: 2008-05-01
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Advisory, Version format compliance
