The structure of the V3 region within gp120 of JR-FL HIV-1 strain (ensemble)

Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 30
  • Selection Criteria: structures with the lowest energy

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Molecular switch for alternative conformations of the HIV-1 V3 region: Implications for phenotype conversion.

Rosen, O.Sharon, M.Quadt-Akabayov, S.R.Anglister, J.

(2006) Proc Natl Acad Sci U S A 13: 13950-13955

  • DOI: https://doi.org/10.1073/pnas.0606312103
  • Primary Citation of Related Structures:
    2ESX, 2ESZ

  • PubMed Abstract:

    HIV-1 coreceptor usage plays a critical role in virus tropism and pathogenesis. A switch from CCR5- to CXCR4-using viruses occurs during the course of HIV-1 infection and correlates with subsequent disease progression. A single mutation at position 322 within the V3 loop of the HIV-1 envelope glycoprotein gp120, from a negatively to a positively charged residue, was found to be sufficient to switch an R5 virus to an X4 virus. In this study, the NMR structure of the V3 region of an R5 strain, HIV-1(JR-FL), in complex with an HIV-1-neutralizing antibody was determined. Positively charged and negatively charged residues at positions 304 and 322, respectively, oppose each other in the beta-hairpin structure, enabling a favorable electrostatic interaction that stabilizes the postulated R5 conformation. Comparison of the R5 conformation with the postulated X4 conformation of the V3 region (positively charged residue at position 322) reveals that electrostatic repulsion between residues 304 and 322 in X4 strains triggers the observed one register shift in the N-terminal strand of the V3 region. We posit that electrostatic interactions at the base of the V3 beta-hairpin can modulate the conformation and thereby influence the phenotype switch. In addition, we suggest that interstrand cation-pi interactions between positively charged and aromatic residues induce the switch to the X4 conformation as a result of the S306R mutation. The existence of three pairs of identical (or very similar) amino acids in the V3 C-terminal strand facilitates the switch between the R5 and X4 conformations.

  • Organizational Affiliation

    Department of Structural Biology, Weizmann Institute of Science, Rehovot 76100, Israel.


Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Envelope polyprotein GP16019Human immunodeficiency virus 1Mutation(s): 0
Gene Names: env
Find proteins for O36236 (Human immunodeficiency virus 1)
Explore O36236
Go to UniProtKB:  O36236
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO36236
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 30
  • Selection Criteria: structures with the lowest energy

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-09-19
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2022-03-09
    Changes: Data collection, Database references, Derived calculations
