2ELZ | pdb_00002elz

Solution structure of the 17th zf-C2H2 domain from human Zinc finger protein 224

PDB DOI: https://doi.org/10.2210/pdb2ELZ/pdb

Classification: TRANSCRIPTION
Organism(s): Homo sapiens
Mutation(s): No

Deposited: 2007-03-28 Released: 2007-10-02
Deposition Author(s): Kurosaki, C., Yoshida, M., Hayashi, F., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Experimental Data Snapshot

Method: SOLUTION NMR
Conformers Calculated: 100
Conformers Submitted: 20
Selection Criteria: structures with the least restraint violations, structures with the lowest energy, target function

wwPDB Validation 3D Report Full Report

Validation slider image for 2ELZ

This is version 1.3 of the entry. See complete history.

Literature

Solution structure of the 17th zf-C2H2 domain from human Zinc finger protein 224

Kurosaki, C., Yoshida, M., Hayashi, F., Yokoyama, S.

To be published.

Macromolecule Content

Total Structure Weight: 4.99 kDa
Atom Count: 341
Modeled Residue Count: 46
Deposited Residue Count: 46
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Zinc finger protein 224	A	46	Homo sapiens	Mutation(s): 0 Gene Names: ZNF224
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NZL3 (Homo sapiens) Explore Q9NZL3 Go to UniProtKB: Q9NZL3
PHAROS: Q9NZL3 GTEx: ENSG00000267680
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9NZL3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: SOLUTION NMR
Conformers Calculated: 100
Conformers Submitted: 20
Selection Criteria: structures with the least restraint violations, structures with the lowest energy, target function

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2007-10-02

Deposition Author(s):

RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History (Full details and data files)

Version 1.0: 2007-10-02
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2022-03-09
Changes: Data collection, Database references, Derived calculations
Version 1.3: 2024-05-29
Changes: Data collection
