2EHE | pdb_00002ehe

Solution structure of the first LIM domain from human four and a half LIM domains protein 3

PDB DOI: https://doi.org/10.2210/pdb2EHE/pdb

Classification: STRUCTURAL PROTEIN
Organism(s): Homo sapiens
Mutation(s): No

Deposited: 2007-03-06 Released: 2007-09-11
Deposition Author(s): Inoue, K., Nagashima, T., Hayashi, F., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Experimental Data Snapshot

Method: SOLUTION NMR
Conformers Calculated: 100
Conformers Submitted: 20
Selection Criteria: structures with the least restraint violations, structures with the lowest energy, target function

wwPDB Validation 3D Report Full Report

Validation slider image for 2EHE

This is version 1.3 of the entry. See complete history.

Literature

Solution structure of the first LIM domain from human four and a half LIM domains protein 3

Inoue, K., Nagashima, T., Hayashi, F., Yokoyama, S.

To be published.

Macromolecule Content

Total Structure Weight: 9.18 kDa
Atom Count: 627
Modeled Residue Count: 82
Deposited Residue Count: 82
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Four and a half LIM domains 3	A	82	Homo sapiens	Mutation(s): 0 Gene Names: FHL3
UniProt & NIH Common Fund Data Resources
Find proteins for Q13643 (Homo sapiens) Explore Q13643 Go to UniProtKB: Q13643
PHAROS: Q13643 GTEx: ENSG00000183386
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q13643
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: SOLUTION NMR
Conformers Calculated: 100
Conformers Submitted: 20
Selection Criteria: structures with the least restraint violations, structures with the lowest energy, target function

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2007-09-11

Deposition Author(s):

RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History (Full details and data files)

Version 1.0: 2007-09-11
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2022-03-09
Changes: Data collection, Database references, Derived calculations
Version 1.3: 2024-05-29
Changes: Data collection
