2CXA

Crystal structure of Leucyl/phenylalanyl-tRNA protein transferase from Escherichia coli


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.6 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.187

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

The crystal structure of leucyl/phenylalanyl-tRNA-protein transferase from Escherichia coli

Dong, X.Kato-Murayama, M.Muramatsu, T.Mori, H.Shirouzu, M.Bessho, Y.Yokoyama, S.

(2007) Protein Sci. 16: 528-534

  • DOI: 10.1110/ps.062616107

  • PubMed Abstract:
  • Leucyl/phenylalanyl-tRNA-protein transferase (L/F-transferase) is an N-end rule pathway enzyme, which catalyzes the transfer of Leu and Phe from aminoacyl-tRNAs to exposed N-terminal Arg or Lys residues of acceptor proteins. Here, we report the 1.6 A ...

    Leucyl/phenylalanyl-tRNA-protein transferase (L/F-transferase) is an N-end rule pathway enzyme, which catalyzes the transfer of Leu and Phe from aminoacyl-tRNAs to exposed N-terminal Arg or Lys residues of acceptor proteins. Here, we report the 1.6 A resolution crystal structure of L/F-transferase (JW0868) from Escherichia coli, the first three-dimensional structure of an L/F-transferase. The L/F-transferase adopts a monomeric structure consisting of two domains that form a bilobate molecule. The N-terminal domain forms a small lobe with a novel fold. The large C-terminal domain has a highly conserved fold, which is observed in the GCN5-related N-acetyltransferase (GNAT) family. Most of the conserved residues of L/F-transferase reside in the central cavity, which exists at the interface between the N-terminal and C-terminal domains. A comparison of the structures of L/F-transferase and the bacterial peptidoglycan synthase FemX, indicated a structural homology in the C-terminal domain, and a similar domain interface region. Although the peptidyltransferase function is shared between the two proteins, the enzymatic mechanism would differ. The conserved residues in the central cavity of L/F-transferase suggest that this region is important for the enzyme catalysis.


    Organizational Affiliation

    RIKEN Genomic Sciences Center, Tsurumi, Yokohama 230-0045, Japan.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Leucyl/phenylalanyl-tRNA-protein transferase
A
256Escherichia coli (strain K12)Mutation(s): 0
Gene Names: aat (ycaA)
EC: 2.3.2.6
Find proteins for P0A8P1 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A8P1
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.6 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.187
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 68.277α = 90.00
b = 44.784β = 108.36
c = 76.376γ = 90.00
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data reduction
SCALEPACKdata scaling
SOLVEphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2005-12-28
    Type: Initial release
  • Version 1.1: 2008-04-30
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
