2BMK

Fab fragment of PLP-dependent catalytic antibody 15A9 in complex with phosphopyridoxyl-D-alanine


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.210

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Structural basis for D-amino acid transamination by the pyridoxal 5'-phosphate-dependent catalytic antibody 15A9.

Golinelli-Pimpaneau, B.Luthi, C.Christen, P.

(2006) J. Biol. Chem. 281: 23969-23977

  • DOI: 10.1074/jbc.M602184200
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Antibody 15A9, raised with 5'-phosphopyridoxyl (PPL)-N(epsilon)-acetyl-L-lysine as hapten, catalyzes the reversible transamination of hydrophobic D-amino acids with pyridoxal 5'-phosphate (PLP). The crystal structures of the complexes of Fab 15A9 wit ...

    Antibody 15A9, raised with 5'-phosphopyridoxyl (PPL)-N(epsilon)-acetyl-L-lysine as hapten, catalyzes the reversible transamination of hydrophobic D-amino acids with pyridoxal 5'-phosphate (PLP). The crystal structures of the complexes of Fab 15A9 with PPL-L-alanine, PPL-D-alanine, and the hapten were determined at 2.3, 2.3, and 2.5A resolution, respectively, and served for modeling the complexes with the corresponding planar imine adducts. The conformation of the PLP-amino acid adduct and its interactions with 15A9 are similar to those occurring in PLP-dependent enzymes, except that the amino acid substrate is only weakly bound, and, due to the immunization and selection strategy, the lysine residue that covalently binds PLP in these enzymes is missing. However, the N-acetyl-L-lysine moiety of the hapten appears to have selected for aromatic residues in hypervariable loop H3 (Trp-H100e and Tyr-H100b), which, together with Lys-H96, create an anion-binding environment in the active site. The structural situation and mutagenesis experiments indicate that two catalytic residues facilitate the transamination reaction of the PLP-D-alanine aldimine. The space vacated by the absent L-lysine side chain of the hapten can be filled, in both PLP-alanine aldimine complexes, by mobile Tyr-H100b. This group can stabilize a hydroxide ion, which, however, abstracts the C alpha proton only from D-alanine. Together with the absence of any residue capable of deprotonating C alpha of L-alanine, Tyr-H100b thus underlies the enantiomeric selectivity of 15A9. The reprotonation of C4' of PLP, the rate-limiting step of 15A9-catalyzed transamination, is most likely performed by a water molecule that, assisted by Lys-H96, produces a hydroxide ion stabilized by the anion-binding environment.


    Related Citations:
    • Monoclonal Antibodies Against N-Alpha-(5'-Phosphopyridoxyl)-L-Lysine.
      Gramatikova, S.I.,Christen, P.
      (1997) J.Biol.Chem. 272: 9779


    Organizational Affiliation

    Laboratoire d'Enzymologie et Biochimie Structurales, CNRS Bât. 34, 1 Avenue de la Terrasse, 91198 Gif-sur-Yvette Cedex, France. beatrice.golinelli@lebs.cnrs-gif.fr




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
FAB FRAGMENT OF CATALYTIC ANTIBODY 15A9, LIGHT CHAIN
A, L
213N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
FAB FRAGMENT OF CATALYTIC ANTIBODY 15A9, HEAVY CHAIN
B, H
226N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
IOD
Query on IOD

Download SDF File
Download CCD File
B, H
IODIDE ION
I
XMBWDFGMSWQBCA-UHFFFAOYSA-M
 Ligand Interaction
PDD
Query on PDD

Download SDF File
Download CCD File
B, L
N-(5'-PHOSPHOPYRIDOXYL)-D-ALANINE
C11 H17 N2 O7 P
WACJCHFWJNNBPR-SSDOTTSWSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
PDDKd: 2400 nM BINDINGMOAD
PDDKd: 2400 nM PDBBIND
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.210
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 63.152α = 90.00
b = 81.152β = 90.35
c = 79.331γ = 90.00
Software Package:
Software NamePurpose
DENZOdata reduction
CNSrefinement
SCALEPACKdata scaling
AMoREphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2006-03-03
    Type: Initial release
  • Version 1.1: 2011-05-08
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2019-02-27
    Type: Data collection, Database references, Experimental preparation, Other
