2B0M

Human dihydroorotate dehydrogenase bound to a novel inhibitor

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.218

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history.


Literature

Brequinar derivatives and species-specific drug design for dihydroorotate dehydrogenase.

Hurt, D.E., Sutton, A.E., Clardy, J.

(2006) Bioorg Med Chem Lett 16: 1610-1615

  • DOI: 10.1016/j.bmcl.2005.12.029
  • Primary Citation of Related Structures:
    2B0M

  • PubMed Abstract:

    • Therapeutic agents brequinar sodium and leflunomide (Arava) work by binding in a hydrophobic tunnel formed by a highly variable N-terminus of family 2 dihydroorotate dehydrogenase (DHODH). The X-ray crystallographic structure of an analog of brequinar bound to human DHODH was determined ...

    Therapeutic agents brequinar sodium and leflunomide (Arava) work by binding in a hydrophobic tunnel formed by a highly variable N-terminus of family 2 dihydroorotate dehydrogenase (DHODH). The X-ray crystallographic structure of an analog of brequinar bound to human DHODH was determined. In silico screening of a library of compounds suggested another subset of brequinar analogs that do not inhibit human DHODH as potentially effective inhibitors of Plasmodium falciparum DHODH.

    Related Citations:
    • Structure of Plasmodium falciparum dihyroorotate dehydrogenase with a bound inhibitor
      Hurt, D.E., Widom, J., Clardy, J.
      () To be published --: --
    Organizational Affiliation:

    Department of Chemistry and Chemical Biology, Cornell University, Ithaca, NY 14850, USA.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Dihydroorotate dehydrogenase, mitochondrialA393Homo sapiensMutation(s): 0
Gene Names: DHODH
EC: 1.3.3.1 (PDB Primary Data), 1.3.5.2 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q02127 (Homo sapiens)
Explore Q02127
Go to UniProtKB:  Q02127
PHAROS:  Q02127
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ02127
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
FMN
Query on FMN
Download Ideal Coordinates CCD File
C [auth A]FLAVIN MONONUCLEOTIDE
C17 H21 N4 O9 P
FVTCRASFADXXNN-SCRDCRAPSA-N		 Ligand Interaction
201
Query on 201
Download Ideal Coordinates CCD File
B [auth A]3-AMIDO-5-BIPHENYL-BENZOIC ACID
C20 H15 N O3
LAZPCGBRHLARSI-UHFFFAOYSA-N		 Ligand Interaction
ORO
Query on ORO
Download Ideal Coordinates CCD File
D [auth A]OROTIC ACID
C5 H4 N2 O4
PXQPEWDEAKTCGB-UHFFFAOYSA-N		 Ligand Interaction
Binding Affinity Annotations
IDSourceBinding Affinity
201 BindingDB:  2B0M Ki: 2800 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.218
  • Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 90.398α = 90
b = 90.398β = 90
c = 123.332γ = 120
Software Package:
Software NamePurpose
HKL-2000data collection
SCALEPACKdata scaling
MOLREPphasing
CNSrefinement
HKL-2000data reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-09-27
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
