2ATZ

Crystal structure of protein HP0184 from Helicobacter pylori

PDB DOI: https://doi.org/10.2210/pdb2ATZ/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Helicobacter pylori 26695
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2005-08-26 Released: 2005-10-11
Deposition Author(s): Chang, C., Xu, X., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.256
R-Value Work: 0.198
R-Value Observed: 0.201

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of protein HP0184 from Helicobacter pylori

Chang, C., Xu, X., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 22.05 kDa
Atom Count: 1,596
Modelled Residue Count: 176
Deposited Residue Count: 180
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
H. pylori predicted coding region HP0184	A	180	Helicobacter pylori 26695	Mutation(s): 5
UniProt
Find proteins for O24984 (Helicobacter pylori (strain ATCC 700392 / 26695)) Explore O24984 Go to UniProtKB: O24984
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O24984
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
DGT Query on DGT Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	2'-DEOXYGUANOSINE-5'-TRIPHOSPHATE C₁₀ H₁₆ N₅ O₁₃ P₃ HAAZLUGHYHWQIW-KVQBGUIXSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.256
R-Value Work: 0.198
R-Value Observed: 0.201
Space Group: P 6₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 77.093	α = 90
b = 77.093	β = 90
c = 118.187	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
DENZO	data reduction
SCALEPACK	data scaling
HKL-3000	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2005-10-11

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2005-10-11
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Source and taxonomy, Version format compliance
