2AJP | pdb_00002ajp

Crystal structure of a human pyridoxal kinase

PDB DOI: https://doi.org/10.2210/pdb2AJP/pdb

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2005-08-02 Released: 2005-08-09
Deposition Author(s): Ismail, S., Dimov, S., Atanassova, A., Tempel, W., Arrowsmith, C., Edwards, A., Sundstrom, M., Weigelt, J., Bochkarev, A., Park, H., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free:
0.283 (Depositor), 0.287 (DCC)
R-Value Work:
0.241 (Depositor), 0.244 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of a human pyridoxal kinase

Ismail, S., Dimov, S., Atanassova, A., Tempel, W., Arrowsmith, C., Edwards, A., Sundstrom, M., Weigelt, J., Bochkarev, A., Park, H., Structural Genomics Consortium (SGC)

To be published.

Macromolecule Content

Total Structure Weight: 74.17 kDa
Atom Count: 4,693
Modeled Residue Count: 604
Deposited Residue Count: 652
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Pyridoxal kinase	A, B	326	Homo sapiens	Mutation(s): 0 Gene Names: PDXK, PKH, PNK EC: 2.7.1.35
UniProt & NIH Common Fund Data Resources
Find proteins for O00764 (Homo sapiens) Explore O00764 Go to UniProtKB: O00764
PHAROS: O00764 GTEx: ENSG00000160209
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O00764
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ANP Query on ANP Download:Ideal Coordinates CCD File SDF format, chain X [auth A] SDF format, chain TA [auth B] MOL2 format, chain X [auth A] MOL2 format, chain TA [auth B] mmCIF format, chain X [auth A] mmCIF format, chain TA [auth B]	TA [auth B], X [auth A]	PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER C₁₀ H₁₇ N₆ O₁₂ P₃ PVKSNHVPLWYQGJ-KQYNXXCUSA-N		Interactions Focus chain TA [auth B] Focus chain X [auth A] Interactions & Density Focus chain TA [auth B] Focus chain X [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain Y [auth B] SDF format, chain C [auth A] MOL2 format, chain Y [auth B] MOL2 format, chain C [auth A] mmCIF format, chain Y [auth B] mmCIF format, chain C [auth A]	C [auth A], Y [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain Y [auth B] Interactions & Density Focus chain C [auth A] Focus chain Y [auth B]
UNX Query on UNX Download:Ideal Coordinates CCD File SDF format, chain Z [auth B] SDF format, chain W [auth A] SDF format, chain V [auth A] SDF format, chain U [auth A] SDF format, chain T [auth A] SDF format, chain SA [auth B] SDF format, chain S [auth A] SDF format, chain RA [auth B] SDF format, chain R [auth A] SDF format, chain QA [auth B] SDF format, chain Q [auth A] SDF format, chain PA [auth B] SDF format, chain P [auth A] SDF format, chain OA [auth B] SDF format, chain O [auth A] SDF format, chain NA [auth B] SDF format, chain N [auth A] SDF format, chain MA [auth B] SDF format, chain M [auth A] SDF format, chain LA [auth B] SDF format, chain L [auth A] SDF format, chain KA [auth B] SDF format, chain K [auth A] SDF format, chain JA [auth B] SDF format, chain J [auth A] SDF format, chain IA [auth B] SDF format, chain I [auth A] SDF format, chain HA [auth B] SDF format, chain H [auth A] SDF format, chain GA [auth B] SDF format, chain G [auth A] SDF format, chain FA [auth B] SDF format, chain F [auth A] SDF format, chain EA [auth B] SDF format, chain E [auth A] SDF format, chain DA [auth B] SDF format, chain D [auth A] SDF format, chain CA [auth B] SDF format, chain BA [auth B] SDF format, chain AA [auth B] MOL2 format, chain Z [auth B] MOL2 format, chain W [auth A] MOL2 format, chain V [auth A] MOL2 format, chain U [auth A] MOL2 format, chain T [auth A] MOL2 format, chain SA [auth B] MOL2 format, chain S [auth A] MOL2 format, chain RA [auth B] MOL2 format, chain R [auth A] MOL2 format, chain QA [auth B] MOL2 format, chain Q [auth A] MOL2 format, chain PA [auth B] MOL2 format, chain P [auth A] MOL2 format, chain OA [auth B] MOL2 format, chain O [auth A] MOL2 format, chain NA [auth B] MOL2 format, chain N [auth A] MOL2 format, chain MA [auth B] MOL2 format, chain M [auth A] MOL2 format, chain LA [auth B] MOL2 format, chain L [auth A] MOL2 format, chain KA [auth B] MOL2 format, chain K [auth A] MOL2 format, chain JA [auth B] MOL2 format, chain J [auth A] MOL2 format, chain IA [auth B] MOL2 format, chain I [auth A] MOL2 format, chain HA [auth B] MOL2 format, chain H [auth A] MOL2 format, chain GA [auth B] MOL2 format, chain G [auth A] MOL2 format, chain FA [auth B] MOL2 format, chain F [auth A] MOL2 format, chain EA [auth B] MOL2 format, chain E [auth A] MOL2 format, chain DA [auth B] MOL2 format, chain D [auth A] MOL2 format, chain CA [auth B] MOL2 format, chain BA [auth B] MOL2 format, chain AA [auth B] mmCIF format, chain Z [auth B] mmCIF format, chain W [auth A] mmCIF format, chain V [auth A] mmCIF format, chain U [auth A] mmCIF format, chain T [auth A] mmCIF format, chain SA [auth B] mmCIF format, chain S [auth A] mmCIF format, chain RA [auth B] mmCIF format, chain R [auth A] mmCIF format, chain QA [auth B] mmCIF format, chain Q [auth A] mmCIF format, chain PA [auth B] mmCIF format, chain P [auth A] mmCIF format, chain OA [auth B] mmCIF format, chain O [auth A] mmCIF format, chain NA [auth B] mmCIF format, chain N [auth A] mmCIF format, chain MA [auth B] mmCIF format, chain M [auth A] mmCIF format, chain LA [auth B] mmCIF format, chain L [auth A] mmCIF format, chain KA [auth B] mmCIF format, chain K [auth A] mmCIF format, chain JA [auth B] mmCIF format, chain J [auth A] mmCIF format, chain IA [auth B] mmCIF format, chain I [auth A] mmCIF format, chain HA [auth B] mmCIF format, chain H [auth A] mmCIF format, chain GA [auth B] mmCIF format, chain G [auth A] mmCIF format, chain FA [auth B] mmCIF format, chain F [auth A] mmCIF format, chain EA [auth B] mmCIF format, chain E [auth A] mmCIF format, chain DA [auth B] mmCIF format, chain D [auth A] mmCIF format, chain CA [auth B] mmCIF format, chain BA [auth B] mmCIF format, chain AA [auth B]	AA [auth B] BA [auth B] CA [auth B] D [auth A] DA [auth B] AA [auth B], BA [auth B], CA [auth B], D [auth A], DA [auth B], E [auth A], EA [auth B], F [auth A], FA [auth B], G [auth A], GA [auth B], H [auth A], HA [auth B], I [auth A], IA [auth B], J [auth A], JA [auth B], K [auth A], KA [auth B], L [auth A], LA [auth B], M [auth A], MA [auth B], N [auth A], NA [auth B], O [auth A], OA [auth B], P [auth A], PA [auth B], Q [auth A], QA [auth B], R [auth A], RA [auth B], S [auth A], SA [auth B], T [auth A], U [auth A], V [auth A], W [auth A], Z [auth B]	UNKNOWN ATOM OR ION X		Interactions Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain D [auth A] Focus chain DA [auth B] Focus chain E [auth A] Focus chain EA [auth B] Focus chain F [auth A] Focus chain FA [auth B] Focus chain G [auth A] Focus chain GA [auth B] Focus chain H [auth A] Focus chain HA [auth B] Focus chain I [auth A] Focus chain IA [auth B] Focus chain J [auth A] Focus chain JA [auth B] Focus chain K [auth A] Focus chain KA [auth B] Focus chain L [auth A] Focus chain LA [auth B] Focus chain M [auth A] Focus chain MA [auth B] Focus chain N [auth A] Focus chain NA [auth B] Focus chain O [auth A] Focus chain OA [auth B] Focus chain P [auth A] Focus chain PA [auth B] Focus chain Q [auth A] Focus chain QA [auth B] Focus chain R [auth A] Focus chain RA [auth B] Focus chain S [auth A] Focus chain SA [auth B] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain W [auth A] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain D [auth A] Focus chain DA [auth B] Focus chain E [auth A] Focus chain EA [auth B] Focus chain F [auth A] Focus chain FA [auth B] Focus chain G [auth A] Focus chain GA [auth B] Focus chain H [auth A] Focus chain HA [auth B] Focus chain I [auth A] Focus chain IA [auth B] Focus chain J [auth A] Focus chain JA [auth B] Focus chain K [auth A] Focus chain KA [auth B] Focus chain L [auth A] Focus chain LA [auth B] Focus chain M [auth A] Focus chain MA [auth B] Focus chain N [auth A] Focus chain NA [auth B] Focus chain O [auth A] Focus chain OA [auth B] Focus chain P [auth A] Focus chain PA [auth B] Focus chain Q [auth A] Focus chain QA [auth B] Focus chain R [auth A] Focus chain RA [auth B] Focus chain S [auth A] Focus chain SA [auth B] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain W [auth A] Focus chain Z [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free: 0.283 (Depositor), 0.287 (DCC)
R-Value Work: 0.241 (Depositor), 0.244 (DCC)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 92.132	α = 90
b = 114.971	β = 90
c = 169.261	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
MOLREP	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2005-08-09

Deposition Author(s):

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2005-08-09
Type: Initial release
Version 1.1: 2008-04-30
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Derived calculations, Version format compliance
Version 1.3: 2017-10-11
Changes: Refinement description
Version 1.4: 2023-08-23
Changes: Data collection, Database references, Derived calculations, Refinement description
