2A5Z | pdb_00002a5z

Crystal Structure of Protein of Unknown Function SO2946 from Shewanella oneidensis MR-1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.02 Å
  • R-Value Free:
    0.203 (Depositor), 0.200 (DCC)
  • R-Value Work:
    0.167 (Depositor), 0.170 (DCC)
  • R-Value Observed:
    0.168 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2A5Z

This is version 1.5 of the entry. See complete history

Literature

Structure of SO2946 orphan from Shewanella oneidensis shows "jelly-roll" fold with carbohydrate-binding module.

Nocek, B.Bigelow, L.Abdullah, J.Joachimiak, A.

(2008) J Struct Funct Genomics 9: 1-6

  • DOI: https://doi.org/10.1007/s10969-008-9040-0
  • Primary Citation Related Structures:
    2A5Z

  • PubMed Abstract:

    The crystal structure of the uncharacterized protein SO2946 from Shewanella oneidensis MR-1 was determined with single-wavelength anomalous diffraction (SAD) and refined to 2.0 A resolution. The SO2946 protein consists of a short helical N-terminal domain and a large C-terminal domain with the "jelly-roll" topology. The protein assembles into a propeller consisting of three C-terminal blades arranged around a central core formed by the N-terminal domains. The function of SO2946 could not be inferred from the sequence since the protein represents an orphan with no sequence homologs, but the protein's structure bears a fold similar to that of proteins containing carbohydrate-binding modules. Features such as fold conservation, the presence of a conserved groove and a metal binding region are indicative that SO2946 may be an enzyme and could be involved in binding carbohydrate molecules.


  • Organizational Affiliation
    • Midwest Center for Structural Genomics, Biosciences Division, Argonne National Laboratory, 9700 South Cass Avenue, Building 202, Argonne, IL 60439, USA.

Macromolecule Content

  • Total Structure Weight: 83.71 kDa
  • Atom Count: 5,936
  • Modeled Residue Count: 722
  • Deposited Residue Count: 786
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
hypothetical protein SO2946
A, B, C
262Shewanella oneidensis MR-1Mutation(s): 7
Gene Names: SO2946
UniProt
Find proteins for Q8ED25 (Shewanella oneidensis (strain ATCC 700550 / JCM 31522 / CIP 106686 / LMG 19005 / NCIMB 14063 / MR-1))
Explore Q8ED25
Go to UniProtKB:  Q8ED25
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8ED25
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.02 Å
  • R-Value Free:  0.203 (Depositor), 0.200 (DCC)
  • R-Value Work:  0.167 (Depositor), 0.170 (DCC)
  • R-Value Observed: 0.168 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 58.59α = 90
b = 53.076β = 95.66
c = 112.652γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
SBC-Collectdata collection
HKL-2000data reduction
HKL-2000data scaling
SHELXCDphasing
SHELXDphasing
SOLVEphasing
RESOLVEphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-08-16
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Advisory, Source and taxonomy, Version format compliance
  • Version 1.3: 2014-11-19
    Changes: Other
  • Version 1.4: 2017-10-11
    Changes: Refinement description
  • Version 1.5: 2024-11-20
    Changes: Data collection, Database references, Derived calculations, Structure summary
