1Z9P

X-Ray structure of a Cu-Zn superoxide dismutase from Haemophilus ducreyi


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.212
  • R-Value Work: 0.170

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Structural basis of heme binding in the Cu,Zn superoxide dismutase from Haemophilus ducreyi.

Toro, I.Petrutz, C.Pacello, F.D'Orazio, M.Battistoni, A.Djinovic-Carugo, K.

(2009) J.Mol.Biol. 386: 406-418

  • DOI: 10.1016/j.jmb.2008.12.004
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The Cu,Zn superoxide dismutase from Haemophilus ducreyi is characterized by the unique ability to bind heme at its dimer interface. Here we report the high-resolution crystal structures of this protein in the heme-loaded (holo) and heme-free (apo) fo ...

    The Cu,Zn superoxide dismutase from Haemophilus ducreyi is characterized by the unique ability to bind heme at its dimer interface. Here we report the high-resolution crystal structures of this protein in the heme-loaded (holo) and heme-free (apo) forms. Heme is asymmetrically bound between the two enzyme subunits, where heme iron is coordinated by two histidine residues, His64 and His 124, provided by the two subunits. Moreover, the binding of heme to the protein is ensured by stabilizing contacts between the prosthetic group and a limited number of other residues, most of which are not present in other bacterial enzyme variants. We show that the introduction of only three mutations at the dimer interface of the enzyme from Haemophilus parainfluenzae, a closely related bacterial species, is sufficient to induce heme-binding ability by this enzyme variant. Heme binding does not alter protein activity. Moreover, the binding of the prosthetic group does not induce any significant structural perturbation at the subunit level and requires only limited local structural rearrangements that widen the cleft at the dimer interface and cause a limited shift in the relative orientation between the subunits. The presence of a preformed heme-binding pocket and the significant solvent exposure of the cofactor to the solvent are compatible with the suggested protective role of the enzyme against heme toxicity or with its involvement in heme trafficking in the periplasmic space.


    Organizational Affiliation

    Structural and Computational Biology Programme, EMBL-Heidelberg, Germany.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Superoxide dismutase [Cu-Zn]
A, B
155Haemophilus ducreyi (strain 35000HP / ATCC 700724)Mutation(s): 0
Gene Names: sodC
EC: 1.15.1.1
Find proteins for Q59452 (Haemophilus ducreyi (strain 35000HP / ATCC 700724))
Go to UniProtKB:  Q59452
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A, B
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
CU
Query on CU

Download SDF File
Download CCD File
A, B
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.212
  • R-Value Work: 0.170
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 71.410α = 90.00
b = 63.990β = 118.04
c = 73.970γ = 90.00
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2006-09-12
    Type: Initial release
  • Version 1.1: 2008-04-30
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2011-10-26
    Type: Database references
