1WHZ

Crystal structure of a hypothetical protein from thermus thermophilus HB8

PDB DOI: https://doi.org/10.2210/pdb1WHZ/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Thermus thermophilus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2004-05-28 Released: 2004-11-28
Deposition Author(s): Kanagawa, M., Yokoyama, S., Kuramitsu, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.52 Å
R-Value Free: 0.209
R-Value Work: 0.148
R-Value Observed: 0.148

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of a hypothetical protein from thermus thermophilus HB8

Kanagawa, M., Yokoyama, S., Kuramitsu, S.

To be published.

Macromolecule Content

Total Structure Weight: 8.36 kDa
Atom Count: 697
Modelled Residue Count: 70
Deposited Residue Count: 70
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hypothetical protein	A	70	Thermus thermophilus	Mutation(s): 0
UniProt
Find proteins for Q5SH17 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8)) Explore Q5SH17 Go to UniProtKB: Q5SH17
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q5SH17
Protein Feature View Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A]	B [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Ligand Interaction

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.52 Å
R-Value Free: 0.209
R-Value Work: 0.148
R-Value Observed: 0.148
Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 27.04	α = 90
b = 27.91	β = 90.31
c = 36.99	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
CrystalClear	data reduction
SCALEPACK	data scaling
SOLVE	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2004-11-28

Deposition Author(s):

RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History (Full details and data files)

Version 1.0: 2004-11-28
Type: Initial release
Version 1.1: 2008-04-30
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Version format compliance
Version 1.3: 2016-09-28
Changes: Other
