Crystal structure of n-aequorin

Experimental Data Snapshot

  • Resolution: 1.60 Å
  • R-Value Free: 0.199
  • R-Value Work: 0.164
  • R-Value Observed: 0.166

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.3 of the entry. See complete history


The crystal structures of semi-synthetic aequorins

Toma, S.Chong, K.T.Nakagawa, A.Teranishi, K.Inouye, S.Shimomura, O.

(2005) Protein Sci 14: 409-416

  • DOI: https://doi.org/10.1110/ps.041067805
  • Primary Citation of Related Structures:
    1UHH, 1UHI, 1UHJ, 1UHK

  • PubMed Abstract:

    The photoprotein aequorin emits light by an intramolecular reaction in the presence of a trace amount of Ca(2+). Semi-synthetic aequorins, produced by replacing the coelenterazine moiety in aequorin with the analogues of coelenterazine, show widely different sensitivities to Ca(2+). To understand the structural basis of the Ca(2+)-sensitivity, we determined the crystal structures of four semi-synthetic aequorins (cp-, i-, br- and n-aequorins) at resolutions of 1.6-1.8 A. In general, the protein structures of these semi-synthetic aequorins are almost identical to native aequorin. Of the four EF-hand domains in the molecule, EF-hand II does not bind Ca(2+), and the loop of EF-hand IV is clearly deformed. It is most likely that the binding of Ca(2+) with EF-hands I and III triggers luminescence. Although little difference was found in the overall structures of aequorins investigated, some significant differences were found in the interactions between the substituents of coelenterazine moiety and the amino acid residues in the binding pocket. The coelenterazine moieties in i-, br-, and n-aequorins have bulky 2-substitutions, which can interfere with the conformational changes of protein structure that follow the binding of Ca(2+) to aequorin. In cp-aequorin, the cyclopentylmethyl group that substitutes for the original 8-benzyl group does not interact hydrophobically with the protein part, giving the coelenterazine moiety more conformational freedom to promote the light-emitting reaction. The differences of various semi-synthetic aequorins in Ca(2+)-sensitivity and reaction rate are explained by the capability of the involved groups and structures to undergo conformational changes in response to the Ca(2+)-binding.

  • Organizational Affiliation

    Institute for Protein Research, Osaka University, 3-2 Yamadaoka, Suita, Osaka 565-0871, Japan.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Aequorin 2
A, B
191Aequorea victoriaMutation(s): 0
Find proteins for P02592 (Aequorea victoria)
Explore P02592
Go to UniProtKB:  P02592
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02592
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on CZN

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
C30 H25 N3 O4
Experimental Data & Validation

Experimental Data

  • Resolution: 1.60 Å
  • R-Value Free: 0.199
  • R-Value Work: 0.164
  • R-Value Observed: 0.166
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 34.223α = 72.35
b = 57.038β = 79.97
c = 57.768γ = 67.89
Software Package:
Software NamePurpose
d*TREKdata reduction
d*TREKdata scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-02-08
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-12-27
    Changes: Data collection, Database references, Derived calculations, Refinement description
