1R53

Crystal structure of the bifunctional chorismate synthase from Saccharomyces cerevisiae


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.2 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.174

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Crystal structure of the bifunctional chorismate synthase from Saccharomyces cerevisiae

Quevillon-Cheruel, S.Leulliot, N.Meyer, P.Graille, M.Bremang, M.Blondeau, K.Sorel, I.Poupon, A.Janin, J.van Tilbeurgh, H.

(2004) J.Biol.Chem. 279: 619-625

  • DOI: 10.1074/jbc.M310380200
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Chorismate synthase (EC 4.2.3.5), the seventh enzyme in the shikimate pathway, catalyzes the transformation of 5-enolpyruvylshikimate 3-phosphate (EPSP) to chorismate, which is the last common precursor in the biosynthesis of numerous aromatic compou ...

    Chorismate synthase (EC 4.2.3.5), the seventh enzyme in the shikimate pathway, catalyzes the transformation of 5-enolpyruvylshikimate 3-phosphate (EPSP) to chorismate, which is the last common precursor in the biosynthesis of numerous aromatic compounds in bacteria, fungi, and plants. The chorismate synthase reaction involves a 1,4-trans-elimination of phosphoric acid from EPSP and has an absolute requirement for reduced FMN as a cofactor. We have determined the three-dimensional x-ray structure of the yeast chorismate synthase from selenomethionine-labeled crystals at 2.2-A resolution. The structure shows a novel betaalphabetaalpha fold consisting of an alternate tight packing of two alpha-helical and two beta-sheet layers, showing no resemblance to any documented protein structure. The molecule is arranged as a tight tetramer with D2 symmetry, in accordance with its quaternary structure in solution. Electron density is missing for 23% of the amino acids, spread over sequence regions that in the three-dimensional structure converge on the surface of the protein. Many totally conserved residues are contained within these regions, and they probably form a structured but mobile domain that closes over a cleft upon substrate binding and catalysis. This hypothesis is supported by previously published spectroscopic measurements implying that the enzyme undergoes considerable structural changes upon binding of both FMN and EPSP.


    Organizational Affiliation

    Institut de Biochimie et de Biophysique Moléculaire et Cellulaire (CNRS-UMR 8619), Université Paris-Sud, Bâtiment 430, 91405 Orsay, France.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Chorismate synthase
A
382Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: ARO2
EC: 4.2.3.5
Find proteins for P28777 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P28777
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.2 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.174
  • Space Group: I 2 2 2
Unit Cell:
Length (Å)Angle (°)
a = 57.516α = 90.00
b = 74.664β = 90.00
c = 155.032γ = 90.00
Software Package:
Software NamePurpose
MOSFLMdata reduction
CCP4data scaling
SOLVEphasing
REFMACrefinement
ARP/wARPmodel building
RESOLVEphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2003-12-23
    Type: Initial release
  • Version 1.1: 2008-04-29
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Derived calculations, Version format compliance
  • Version 1.3: 2017-10-11
    Type: Advisory, Refinement description
