1PNG

CRYSTAL STRUCTURE OF PEPTIDE-N(4)-(N-ACETYL-BETA-D-GLUCOSAMINYL) ASPARAGINE AMIDASE AT 2.2 ANGSTROMS RESOLUTION


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Work: 0.183

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Crystal structure of peptide-N4-(N-acetyl-beta-D-glucosaminyl)asparagine amidase F at 2.2-A resolution.

Kuhn, P.Tarentino, A.L.Plummer Jr., T.H.Van Roey, P.

(1994) Biochemistry 33: 11699-11706

  • DOI: 10.1021/bi00205a005
  • Primary Citation of Related Structures:
    1PNG

  • PubMed Abstract:
  • Peptide-N4-(N-acetyl-beta-D-glucosaminyl)asparagine amidase F (PNGase F) is an amidase that cleaves the beta-aspartylglucosylamine bond of asparagine-linked glycans. The 34.8-kDa (314 amino acids) enzyme has a very broad substrate specificity and is extensively used for studies of the structure and function of glycoproteins ...

    Peptide-N4-(N-acetyl-beta-D-glucosaminyl)asparagine amidase F (PNGase F) is an amidase that cleaves the beta-aspartylglucosylamine bond of asparagine-linked glycans. The 34.8-kDa (314 amino acids) enzyme has a very broad substrate specificity and is extensively used for studies of the structure and function of glycoproteins. Enzymatic activity of PNGase F requires recognition of both the peptide and the carbohydrate components of the substrate. Only limited information regarding the mechanism of action of the enzyme is available. The three-dimensional structure of PNGase F has been determined by X-ray crystallography at 2.2-A resolution. The protein folds into two domains comprising residues 1-137 and 143-314, respectively. Both domains have eight-stranded antiparallel beta-sandwich motifs that are very similar in geometry. Both sandwiches have parallel principal axes and lie side by side. The covalent link between the domains is located at the top end of the molecule. Extensive hydrogen-bonding contacts occur along the full length of the interface between the two domains. Three different areas, all at the interface between the two domains, have been identified as possible locations for the active site of the enzyme. These include a hydrophobic bowl of about 20 A in diameter on one surface of the molecule, a long polar cleft on the opposite side, and a cleft at the bottom, which is lined with large aromatic residues including eight tryptophans.


    Related Citations:
    • Crystallization and Preliminary Crystallographic Analysis of Peptide-N(4)-(N-Acetyl-Beta-D-Glucosaminyl) Asparagine Amidase (Pngasef)
      Kuhn, P., Tarentino, A.L., Plummer Junior, T.H., Van Roey, P.
      (1994) J Mol Biol 241: 622

    Organizational Affiliation

    Wadsworth Center, New York State Department of Health, Albany 12201-0509.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
PEPTIDE-N(4)-(N-ACETYL-BETA-D-GLUCOSAMINYL)ASPARAGINE AMIDASE FA314Elizabethkingia meningosepticaMutation(s): 0
EC: 3.5.1.52
UniProt
Find proteins for P21163 (Elizabethkingia miricola)
Explore P21163
Go to UniProtKB:  P21163
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Work: 0.183
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 87.16α = 90
b = 125.1β = 90
c = 79.33γ = 90

Structure Validation

View Full Validation Report




Entry History

Deposition Data

  • Deposited Date: 1994-06-02
  • Released Date: 1994-11-30
  • Deposition Author(s): Van Roey, P., Kuhn, P.

Revision History  (Full details and data files)

  • Version 1.0: 1994-11-30
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-11-29
    Changes: Derived calculations, Other
