1O6W

Solution Structure of the Prp40 WW Domain Pair of the Yeast Splicing Factor Prp40


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 20
  • Conformers Submitted:
  • Selection Criteria: STRUCTURES WITH ACCEPTABLE COVALEN GEOMETRY, STRUCTURES WITH FAVORABL NON-BOND ENERGY

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Solution Structure and Ligand Recognition of the Ww Domain Pair of the Yeast Splicing Factor Prp40

Wiesner, S.Stier, G.Sattler, M.Macias, M.J.

(2002) J Mol Biol 324: 807

  • DOI: https://doi.org/10.1016/s0022-2836(02)01145-2
  • Primary Citation of Related Structures:
    1O6W

  • PubMed Abstract:

    The yeast splicing factor pre-mRNA processing protein 40 (Prp40) comprises two N-terminal WW domains, separated by a ten-residue linker, and six consecutive FF domains. In the spliceosome, the Prp40 WW domains participate in cross-intron bridging by interacting with proline-rich regions present in the branch-point binding protein (BBP) and the U5 small nuclear ribonucleoprotein component Prp8. Furthermore, binding of Prp40 to the phosphorylated C-terminal domain (CTD) of the largest subunit of RNA polymerase II is thought to link splicing to transcription. To gain insight into this complex interaction network we have determined the solution structure of the tandem Prp40 WW domains by NMR spectroscopy and performed chemical shift mapping experiments with different proline-rich peptides. The WW domains each adopt the characteristic triple-stranded beta-sheet structure and are connected by a stable alpha-helical linker. On the basis of a detailed analysis of residual dipolar couplings (RDC) and 15N relaxation data we show that the tandem Prp40 WW domains behave in solution as a single folded unit with unique alignment and diffusion tensor, respectively. Using [1H-15N]-RDCs, we were able to accurately define the relative orientation of the WW domains revealing that the binding pockets of each domain face opposite sides of the structure. Furthermore, we found that both Prp40 WW domains interact with PPxY motifs (where x is any residue) present in peptides derived from the splicing factors BBP and Prp8. Moreover, the Prp40 WW domains are shown to bind proline-rich peptides devoid of aromatic residues, which are also recognised by the Abl-SH3 domain and the WW domain of the mammalian Prp40 orthologue formin binding protein 11. In contrast, no interaction was observed between the Prp40 WW domains and the CTD repeats used in this work.


  • Organizational Affiliation

    Structural Biology Programme, EMBL Heidelberg, Meyerhofstr. 1, 69117 Heidelberg, Germany. weisner@nmr.embl-heidelberg.de


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
PRE-MRNA PROCESSING PROTEIN PRP4075Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P33203 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P33203
Go to UniProtKB:  P33203
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP33203
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 20
  • Conformers Submitted:
  • Selection Criteria: STRUCTURES WITH ACCEPTABLE COVALEN GEOMETRY, STRUCTURES WITH FAVORABL NON-BOND ENERGY

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2002-12-04
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2020-01-15
    Changes: Data collection, Other
