Crystal Structure of Pyruvate and Mg2+ bound 2-methylisocitrate lyase (PrpB) from Salmonella typhimurium

Experimental Data Snapshot

  • Resolution: 2.30 Å
  • R-Value Free: 0.251
  • R-Value Work: 0.200
  • R-Value Observed: 0.200

wwPDB Validation   3D Report Full Report

This is version 2.0 of the entry. See complete history


Crystal structure of Salmonella typhimurium 2-methylisocitrate lyase (PrpB) and its complex with pyruvate and Mg(2+)

Simanshu, D.K.Satheshkumar, P.S.Savithri, H.S.Murthy, M.R.N.

(2003) Biochem Biophys Res Commun 311: 193-201

  • DOI: https://doi.org/10.1016/j.bbrc.2003.09.193
  • Primary Citation of Related Structures:
    1O5Q, 1UJQ

  • PubMed Abstract:

    Propionate metabolism in Salmonella typhimurium occurs via 2-methylcitric acid cycle. The last step of this cycle, the cleavage of 2-methylisocitrate to succinate and pyruvate, is catalysed by 2-methylisocitrate lyase (PrpB). Here we report the X-ray crystal structure of the native and the pyruvate/Mg(2+) bound PrpB from S. typhimurium, determined at 2.1 and 2.3A, respectively. The structure closely resembles that of the Escherichia coli enzyme. Unlike the E. coli PrpB, Mg(2+) could not be located in the native Salmonella PrpB. Only in pyruvate bound PrpB structure, Mg(2+) was found coordinated with pyruvate. Binding of pyruvate to PrpB seems to induce movement of the Mg(2+) by 2.5A from its position found in E. coli native PrpB. In both the native enzyme and pyruvate/Mg(2+) bound forms, the active site loop is completely disordered. Examination of the pocket in which pyruvate and glyoxalate bind to 2-methylisocitrate lyase and isocitrate lyase, respectively, reveals plausible rationale for different substrate specificities of these two enzymes. Structural similarities in substrate and metal atom binding site as well as presence of similar residues in the active site suggest possible similarities in the reaction mechanism.

  • Organizational Affiliation

    Molecular Biophysics Unit, Indian Institute of Science, Bangalore, India.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Probable methylisocitrate lyase
A, B, C, D
305Salmonella enterica subsp. enterica serovar TyphimuriumMutation(s): 0
Gene Names: prpB
Find proteins for Q56062 (Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720))
Explore Q56062
Go to UniProtKB:  Q56062
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56062
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.30 Å
  • R-Value Free: 0.251
  • R-Value Work: 0.200
  • R-Value Observed: 0.200
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.953α = 90
b = 99.679β = 90
c = 202.396γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2003-11-25
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-10-25
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 2.0: 2023-11-15
    Changes: Atomic model, Data collection, Derived calculations
