1NM5

R. rubrum transhydrogenase (dI.Q132N)2(dIII)1 asymmetric complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.236
  • R-Value Observed: 0.238

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Glutamine 132 in the NAD(H)-binding component of proton-translocating transhydrogenase tethers the nucleotides before hydride transfer.

van Boxel, G.I.Quirk, P.G.Cotton, N.P.White, S.A.Jackson, J.B.

(2003) Biochemistry 42: 1217-1226

  • DOI: https://doi.org/10.1021/bi027032e
  • Primary Citation of Related Structures:
    1NM5

  • PubMed Abstract:
  • Transhydrogenase, found in bacterial membranes and inner mitochondrial membranes of animal cells, couples the redox reaction between NAD(H) and NADP(H) to proton translocation. In this work, the invariant Gln132 in the NAD(H)-binding component (dI) of the Rhodospirillum rubrum transhydrogenase was substituted with Asn (to give dI ...

    Transhydrogenase, found in bacterial membranes and inner mitochondrial membranes of animal cells, couples the redox reaction between NAD(H) and NADP(H) to proton translocation. In this work, the invariant Gln132 in the NAD(H)-binding component (dI) of the Rhodospirillum rubrum transhydrogenase was substituted with Asn (to give dI.Q132N). Mixtures of the mutant protein and the NADP(H)-binding component (dIII) of the enzyme readily produced an asymmetric complex, (dI.Q132N)(2)dIII(1). The X-ray structure of the complex revealed specific changes in the interaction between bound nicotinamide nucleotides and the protein at the hydride transfer site. The first-order rate constant of the redox reaction between nucleotides bound to (dI.Q132N)(2)dIII(1) was <1% of that for the wild-type complex, and the deuterium isotope effect was significantly decreased. The nucleotide binding properties of the dI component in the complex were asymmetrically affected by the Gln-to-Asn mutation. In intact, membrane-bound transhydrogenase, the substitution completely abolished all catalytic activity. The results suggest that Gln132 in the wild-type enzyme behaves as a "tether" or a "tie" in the mutual positioning of the (dihydro)nicotinamide rings of NAD(H) and NADP(H) for hydride transfer during the conformational changes that are coupled to the translocation of protons across the membrane. This ensures that hydride transfer is properly gated and does not take place in the absence of proton translocation.


    Related Citations:
    • The crystal Structure of an Asymmetric Complex of the Two Nucleotide Binding Components of Proton-Translocating Transhydrogenase
      Cotton, N.P., White, S.A., Peake, S.J., McSweeney, S., Jackson, J.B.
      (2001) Structure 9: 165

    Organizational Affiliation

    School of Biosciences, University of Birmingham, Edgbaston, Birmingham B15 2TT, UK.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
NAD(P) transhydrogenase subunit alpha part 1A, B384Rhodospirillum rubrumMutation(s): 1
Gene Names: PNT
EC: 1.6.1.2 (PDB Primary Data), 7.1.1.1 (UniProt)
UniProt
Find proteins for Q2RSB2 (Rhodospirillum rubrum (strain ATCC 11170 / ATH 1.1.1 / DSM 467 / LMG 4362 / NCIMB 8255 / S1))
Explore Q2RSB2
Go to UniProtKB:  Q2RSB2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ2RSB2
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
NAD(P) transhydrogenase subunit betaC203Rhodospirillum rubrumMutation(s): 0
Gene Names: PNT
EC: 1.6.1.2 (PDB Primary Data), 7.1.1.1 (UniProt)
UniProt
Find proteins for Q2RSB4 (Rhodospirillum rubrum (strain ATCC 11170 / ATH 1.1.1 / DSM 467 / LMG 4362 / NCIMB 8255 / S1))
Explore Q2RSB4
Go to UniProtKB:  Q2RSB4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ2RSB4
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NAP
Query on NAP

Download Ideal Coordinates CCD File
G [auth C]NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE
C21 H28 N7 O17 P3
XJLXINKUBYWONI-NNYOXOHSSA-N
 Ligand Interaction
NAD
Query on NAD

Download Ideal Coordinates CCD File
D [auth A],
E [auth B]
NICOTINAMIDE-ADENINE-DINUCLEOTIDE
C21 H27 N7 O14 P2
BAWFJGJZGIEFAR-NNYOXOHSSA-N
 Ligand Interaction
GOL
Query on GOL

Download Ideal Coordinates CCD File
F [auth B]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Binding Affinity Annotations
IDSourceBinding Affinity
NAD Binding MOAD:  1NM5 Kd: 2.00e+4 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.236
  • R-Value Observed: 0.238
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 71.939α = 90
b = 73.886β = 90
c = 205.257γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
MOSFLMdata reduction
CCP4data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2004-01-13
    Type: Initial release
  • Version 1.1: 2008-04-29
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 1.3: 2021-10-27
    Changes: Database references, Derived calculations
