Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 15
  • Selection Criteria: target function

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Solution structure of the ribosome recycling factor from Aquifex aeolicus.

Yoshida, T.Uchiyama, S.Nakano, H.Kashimori, H.Kijima, H.Ohshima, T.Saihara, Y.Ishino, T.Shimahara, H.Yoshida, T.Yokose, K.Ohkubo, T.Kaji, A.Kobayashi, Y.

(2001) Biochemistry 40: 2387-2396

  • DOI: https://doi.org/10.1021/bi002474g
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    The solution structure of ribosome recycling factor (RRF) from hyperthermophilic bacterium, Aquifex aeolicus, was determined by heteronuclear multidimensional NMR spectroscopy. Fifteen structures were calculated using restraints derived from NOE, J-coupling, and T1/T2 anisotropies. The resulting structure has an overall L-shaped conformation with two domains and is similar to that of a tRNA molecule. The domain I (corresponding to the anticodon stem of tRNA) is a rigid three alpha-helix bundle. Being slightly different from usual coiled-coil arrangements, each helix of domain I is not twisted but straight and parallel to the main axis. The domain II (corresponding to the portion with the CCA end of tRNA) is an alpha/beta domain with an alpha-helix and two beta-sheets, that has some flexible regions. The backbone atomic root-mean-square deviation (rmsd) values of both domains were 0.7 A when calculated separately, which is smaller than that of the molecule as a whole (1.4 A). Measurement of 15N-[1H] NOE values show that the residues in the corner of the L-shaped molecule are undergoing fast internal motion. These results indicate that the joint region between two domains contributes to the fluctuation in the orientation of two domains. Thus, it was shown that RRF remains the tRNA mimicry in solution where it functions.

  • Organizational Affiliation

    Graduate School of Pharmaceutical Sciences, Osaka University, 1-6 Yamadaoka, Suita, Osaka 565-0871, Japan.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
RIBOSOME RECYCLING FACTOR184Aquifex aeolicusMutation(s): 0
Find proteins for O66928 (Aquifex aeolicus (strain VF5))
Explore O66928
Go to UniProtKB:  O66928
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO66928
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 15
  • Selection Criteria: target function

Structure Validation

View Full Validation Report

Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2001-05-16
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2022-02-23
    Changes: Database references, Derived calculations
