1F4G

CRYSTAL STRUCTURE OF E. COLI THYMIDYLATE SYNTHASE COMPLEXED WITH SP-876


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.180

wwPDB Validation 3D Report Full Report


This is version 1.5 of the entry. See complete history

Literature

Site-directed ligand discovery.

Erlanson, D.A.Braisted, A.C.Raphael, D.R.Randal, M.Stroud, R.M.Gordon, E.M.Wells, J.A.

(2000) Proc.Natl.Acad.Sci.USA 97: 9367-9372

  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • We report a strategy (called "tethering") to discover low molecular weight ligands ( approximately 250 Da) that bind weakly to targeted sites on proteins through an intermediary disulfide tether. A native or engineered cysteine in a protein is allowe ...

    We report a strategy (called "tethering") to discover low molecular weight ligands ( approximately 250 Da) that bind weakly to targeted sites on proteins through an intermediary disulfide tether. A native or engineered cysteine in a protein is allowed to react reversibly with a small library of disulfide-containing molecules ( approximately 1,200 compounds) at concentrations typically used in drug screening (10 to 200 microM). The cysteine-captured ligands, which are readily identified by MS, are among the most stable complexes, even though in the absence of the covalent tether the ligands may bind very weakly. This method was applied to generate a potent inhibitor for thymidylate synthase, an essential enzyme in pyrimidine metabolism with therapeutic applications in cancer and infectious diseases. The affinity of the untethered ligand (K(i) approximately 1 mM) was improved 3,000-fold by synthesis of a small set of analogs with the aid of crystallographic structures of the tethered complex. Such site-directed ligand discovery allows one to nucleate drug design from a spatially targeted lead fragment.


    Organizational Affiliation

    Sunesis Pharmaceuticals, Incorporated, Redwood City, CA 94063, USA. erlanson@sunesis-pharma.com




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
THYMIDYLATE SYNTHASE
A, B
264Escherichia coli (strain K12)Mutation(s): 2
Gene Names: thyA
EC: 2.1.1.45
Find proteins for P0A884 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A884
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
GOL
Query on GOL

Download SDF File
Download CCD File
A
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
TP4
Query on TP4

Download SDF File
Download CCD File
A, B
N-[4-[[GLUTAMIC ACID]-CARBONYL]-BENZENE-SULFONYL-D-PROLINYL]-3-AMINO-PROPANOIC ACID
SP-876
C20 H25 N3 O10 S
SRAHBOKVSSZEHQ-LSDHHAIUSA-N
 Ligand Interaction
Modified Residues  2 Unique
IDChainsTypeFormula2D DiagramParent
CXM
Query on CXM
A, B
L-PEPTIDE LINKINGC6 H11 N O4 SMET
MHO
Query on MHO
A, B
L-PEPTIDE LINKINGC5 H11 N O3 SMET
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
TP4Ki: 330 nM BINDINGMOAD
TP4Ki: 330 nM PDBBIND
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.180
  • Space Group: P 63
Unit Cell:
Length (Å)Angle (°)
a = 126.030α = 90.00
b = 126.030β = 90.00
c = 66.840γ = 120.00
Software Package:
Software NamePurpose
AMoREphasing
d*TREKdata scaling
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2000-06-22
    Type: Initial release
  • Version 1.1: 2008-04-27
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Non-polymer description, Version format compliance
  • Version 1.3: 2017-10-04
    Type: Refinement description
  • Version 1.4: 2018-01-31
    Type: Experimental preparation
  • Version 1.5: 2018-02-28
    Type: Experimental preparation
