Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 15
  • Selection Criteria: LEAST RESTRAINT VIOLATION

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


SH3 in muscles: solution structure of the SH3 domain from nebulin.

Politou, A.S.Millevoi, S.Gautel, M.Kolmerer, B.Pastore, A.

(1998) J Mol Biol 276: 189-202

  • DOI: https://doi.org/10.1006/jmbi.1997.1521
  • Primary Citation of Related Structures:
    1ARK, 1NEB

  • PubMed Abstract:

    The huge modular protein nebulin is located in the thin filament of striated muscle in vertebrates and is thought to bind and stabilize F-actin. The C-terminal part of human nebulin is anchored in the sarcomeric Z-disk and contains an SH3 domain, the first of such motifs to be identified in a myofibrillar protein. We have determined the nebulin SH3 sequence from several species and found it strikingly conserved. We have also shown that the SH3 transcripts are constitutively expressed in skeletal muscle tissues. As the first step towards a molecular understanding of nebulin's cellular role we have determined the three-dimensional structure of the human nebulin SH3 domain in solution by nuclear magnetic resonance (NMR) spectroscopy and compared it with other known SH3 structures. The nebulin SH3 domain has a well-defined structure in solution with a typical SH3 topology, consisting of a beta-sandwich of two triple-stranded, antiparallel beta-sheets arranged at right angles to each other and of a single turn of a 310-helix. An additional double-stranded antiparallel beta-sheet in the RT loop bends over the beta-sandwich. The derived structure reveals a remarkable similarity with a distinct subset of SH3 domains, especially in the structural features of the exposed hydrophobic patch that is thought to be the site of interaction with polyproline ligands. On the basis of this similarity, we have modelled the interaction with an appropriate polyproline ligand and attempted to delineate the characteristics of the physiological SH3-binding partner in the Z-disk. Our results represent the first step in reconstructing the structure of nebulin and are expected to contribute to our understanding of nebulin's functional role in myofibrillar assembly.

  • Organizational Affiliation

    Chemistry Department University of Crete, Heraklion, Greece.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
NEBULIN60Homo sapiensMutation(s): 0
Gene Names: NEB
UniProt & NIH Common Fund Data Resources
Find proteins for P20929 (Homo sapiens)
Explore P20929
Go to UniProtKB:  P20929
PHAROS:  P20929
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP20929
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 15
  • Selection Criteria: LEAST RESTRAINT VIOLATION

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1998-01-28
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2022-02-16
    Changes: Database references, Derived calculations, Other
