1Z1A

S. cerevisiae Sir1 ORC-interaction domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.274
  • R-Value Work: 0.238

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structural basis of the Sir1-origin recognition complex interaction in transcriptional silencing.

Hou, Z.Bernstein, D.A.Fox, C.A.Keck, J.L.

(2005) Proc.Natl.Acad.Sci.Usa 102: 8489-8494

  • DOI: 10.1073/pnas.0503525102
  • Primary Citation of Related Structures:  1ZHI

  • PubMed Abstract:
  • The Sir1 protein plays a key role in establishing a silent chromatin structure at the cryptic mating-type loci HMR and HML in Saccharomyces cerevisiae by interacting with the bromo-adjacent homology (BAH) domain of the Orc1p subunit of the origin rec ...

    The Sir1 protein plays a key role in establishing a silent chromatin structure at the cryptic mating-type loci HMR and HML in Saccharomyces cerevisiae by interacting with the bromo-adjacent homology (BAH) domain of the Orc1p subunit of the origin recognition complex (ORC). Here, we present the high-resolution crystal structures of the ORC interaction region (OIR) of Sir1p and that of the complex formed between the OIR and BAH domains. Amino acids within the OIR previously shown to be required for a Sir1p/ORC interaction are presented on a conserved, convex surface that forms a complementary interface with a concave region of the Orc1 BAH domain that is critical for transcriptional silencing. The OIR/BAH interaction surface comprises a network of hydrophobic and polar/ionic interactions between discrete structural modules in each protein and involves several residues that were not implicated in previous studies. These data provide important structural insights into a protein-protein interaction critical for the formation of a specialized chromatin domain within eukaryotic chromosomes.


    Organizational Affiliation

    Department of Biomolecular Chemistry, University of Wisconsin Medical School, Medical Sciences Center, 1300 University Avenue, Madison, WI 53706-1532, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Regulatory protein SIR1
A, B
142Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: SIR1
Find proteins for P21691 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P21691
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.274
  • R-Value Work: 0.238
  • Space Group: P 32 2 1
Unit Cell:
Length (Å)Angle (°)
a = 60.928α = 90.00
b = 60.928β = 90.00
c = 159.257γ = 120.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
REFMACrefinement
SOLVEphasing
HKL-2000data reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2005-06-07
    Type: Initial release
  • Version 1.1: 2008-04-30
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Advisory, Version format compliance
