1YQY

Structure of B. Anthrax Lethal factor in complex with a hydroxamate inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.191
  • R-Value Observed: 0.196

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Anthrax lethal factor inhibition.

Shoop, W.L.Xiong, Y.Wiltsie, J.Woods, A.Guo, J.Pivnichny, J.V.Felcetto, T.Michael, B.F.Bansal, A.Cummings, R.T.Cunningham, B.R.Friedlander, A.M.Douglas, C.M.Patel, S.B.Wisniewski, D.Scapin, G.Salowe, S.P.Zaller, D.M.Chapman, K.T.Scolnick, E.M.Schmatz, D.M.Bartizal, K.MacCoss, M.Hermes, J.D.

(2005) Proc Natl Acad Sci U S A 102: 7958-7963

  • DOI: https://doi.org/10.1073/pnas.0502159102
  • Primary Citation of Related Structures:
    1YQY

  • PubMed Abstract:

    The primary virulence factor of Bacillus anthracis is a secreted zinc-dependent metalloprotease toxin known as lethal factor (LF) that is lethal to the host through disruption of signaling pathways, cell destruction, and circulatory shock. Inhibition of this proteolytic-based LF toxemia could be expected to provide therapeutic value in combination with an antibiotic during and immediately after an active anthrax infection. Herein is shown the crystal structure of an intimate complex between a hydroxamate, (2R)-2-[(4-fluoro-3-methylphenyl)sulfonylamino]-N-hydroxy-2-(tetrahydro-2H-pyran-4-yl)acetamide, and LF at the LF-active site. Most importantly, this molecular interaction between the hydroxamate and the LF active site resulted in (i) inhibited LF protease activity in an enzyme assay and protected macrophages against recombinant LF and protective antigen in a cell-based assay, (ii) 100% protection in a lethal mouse toxemia model against recombinant LF and protective antigen, (iii) approximately 50% survival advantage to mice given a lethal challenge of B. anthracis Sterne vegetative cells and to rabbits given a lethal challenge of B. anthracis Ames spores and doubled the mean time to death in those that died in both species, and (iv) 100% protection against B. anthracis spore challenge when used in combination therapy with ciprofloxacin in a rabbit "point of no return" model for which ciprofloxacin alone provided 50% protection. These results indicate that a small molecule, hydroxamate LF inhibitor, as revealed herein, can ameliorate the toxemia characteristic of an active B. anthracis infection and could be a vital adjunct to our ability to combat anthrax.


  • Organizational Affiliation

    Merck Research Laboratories, Rahway, NJ 07065, USA. weseley_shoop@merck.com


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Lethal factor523Bacillus anthracisMutation(s): 1
Gene Names: lef
EC: 3.4.24.83
UniProt
Find proteins for P15917 (Bacillus anthracis)
Explore P15917
Go to UniProtKB:  P15917
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP15917
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
915
Query on 915

Download Ideal Coordinates CCD File
C [auth A](2R)-2-{[(4-FLUORO-3-METHYLPHENYL)SULFONYL]AMINO}-N-HYDROXY-2-TETRAHYDRO-2H-PYRAN-4-YLACETAMIDE
C14 H19 F N2 O5 S
LUCFRFDOOYLALP-CYBMUJFWSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
B [auth A]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
915 PDBBind:  1YQY Ki: 24 (nM) from 1 assay(s)
BindingDB:  1YQY Ki: 24 (nM) from 1 assay(s)
IC50: 54 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.191
  • R-Value Observed: 0.196
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 57.332α = 90
b = 75.957β = 90
c = 139.006γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
SCALEPACKdata scaling
MOLREPphasing
autoBUSTERrefinement
HKL-2000data reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-05-31
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-08-23
    Changes: Data collection, Database references, Derived calculations, Refinement description
