1YHA | pdb_00001yha

CRYSTAL STRUCTURES OF Y41H AND Y41F MUTANTS OF GENE V PROTEIN FROM FF PHAGE SUGGEST POSSIBLE PROTEIN-PROTEIN INTERACTIONS IN GVP-SSDNA COMPLEX


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Work:
    0.170 (Depositor)
  • R-Value Observed:
    0.170 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1YHA

This is version 1.4 of the entry. See complete history

Literature

Crystal structures of Y41H and Y41F mutants of gene V protein from Ff phage suggest possible protein-protein interactions in the GVP-ssDNA complex.

Guan, Y.Zhang, H.Konings, R.N.Hilbers, C.W.Terwilliger, T.C.Wang, A.H.

(1994) Biochemistry 33: 7768-7778

  • Primary Citation Related Structures:
    1YHA, 1YHB

  • PubMed Abstract:

    Gene V protein (GVP) encoded by the filamentous phage Ff (M13, fl, fd) is a homodimeric protein of 87 amino acids that binds to single-stranded DNA (ssDNA) nonspecifically and cooperatively. The structure (monoclinic C2 form) of the wild-type protein has been determined and refined at 1.8-A resolution [Skinner et al. (1994) Proc. Natl. Acad. Sci. U.S.A. 91, 2071-2075]. The monomer structure consists of a somewhat distorted five-stranded beta-barrel core with three prominent loops: a DNA-binding loop, a dyad loop, and a dimer contact loop. The amino acid residue at position 41 plays an important role in the dimer-dimer interactions of the protein-ssDNA complex. Two Y41 mutant structures have been studied by X-ray crystallography. The Y41F GVP structure has been refined to an R-factor of 0.180 at 2.2-A resolution and is very similar to the wild-type (wt) structure (rmsd of all C alpha atoms = 0.30 A). In contrast, Y41H GVP forms a new crystal lattice in the space group P2(1)2(1)2(1) with a = 77.18 A, b = 84.17 A, and c = 28.62 A. Its structure has been solved by the molecular replacement method and refined to an R-factor of 0.170 at 2.5-A resolution. The two monomers of Y41H are crystallographically independent, and their structures remain similar to wt-GVP but with significant differences, particularly in the DNA-binding hairpin region. In both crystals, the loop (residues 36-43) that contains the Y41 residue is involved in the crystal dimer packings but in a different manner. The dimer-dimer contacts found in the wt-GVP crystal may be important for GVP aggregation in the absence of DNA. In the presence of DNA, the dimer-dimer contacts may switch to the type found in the Y41H crystal, allowing the GVP-ssDNA complex to form cooperatively. A model of the complex, consistent with existing biochemical and biophysical data, has been constructed from those crystal packing data.


  • Organizational Affiliation
    • Biophysics Division, University of Illinois at Urbana-Champaign 61801.

Macromolecule Content

  • Total Structure Weight: 19.35 kDa
  • Atom Count: 1,391
  • Modeled Residue Count: 174
  • Deposited Residue Count: 174
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
GENE V PROTEIN
A, B
87Enterobacteria phage f1Mutation(s): 0
UniProt
Find proteins for P69543 (Enterobacteria phage f1)
Explore P69543
Go to UniProtKB:  P69543
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP69543
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Work:  0.170 (Depositor)
  • R-Value Observed: 0.170 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 77.18α = 90
b = 84.17β = 90
c = 28.62γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
X-PLORrefinement
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1994-06-22
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-11-29
    Changes: Derived calculations, Other, Structure summary
  • Version 1.4: 2024-02-14
    Changes: Data collection, Database references
