1WZZ

Structure of endo-beta-1,4-glucanase CMCax from Acetobacter xylinum


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.176

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structural characterization of the Acetobacter xylinum endo-beta-1,4-glucanase CMCax required for cellulose biosynthesis.

Yasutake, Y.Kawano, S.Tajima, K.Yao, M.Satoh, Y.Munekata, M.Tanaka, I.

(2006) Proteins 64: 1069-1077

  • DOI: 10.1002/prot.21052

  • PubMed Abstract:
  • Previous studies have demonstrated that endoglucanase is required for cellulose biosynthesis both in bacteria and plants. However, it has yet to be elucidated how the endoglucanases function in the mechanism of cellulose biosynthesis. Here we describ ...

    Previous studies have demonstrated that endoglucanase is required for cellulose biosynthesis both in bacteria and plants. However, it has yet to be elucidated how the endoglucanases function in the mechanism of cellulose biosynthesis. Here we describe the crystal structure of the cellulose biosynthesis-related endo-beta-1,47-glucanase (CMCax; EC 3.2.1.4) from the cellulose-producing Gramnegative bacterium, Acetobacter xylinum (= Gluconacetobacter xylinus), determined at 1.65-A resolution. CMCax falls into the glycoside hydrolase family 8 (GH-8), and the structure showed that the overall fold of the CMCax is similar to those of other glycoside hydrolases belonging to GH-8. Structure comparison with Clostridium thermocellum CelA, the best characterized GH-8 endoglucanase, revealed that sugar recognition subsite +3 is completely missing in CMCax. The absence of the subsite +3 leads to significant broadness of the cleft at the cellooligosaccharide reducing-end side. CMCax is known to be a secreted enzyme and is present in the culture medium. However, electron microscopic analysis using immunostaining clearly demonstrated that a portion of CMCax is localized to the cell surface, suggesting a link with other known membrane-anchored endoglucanases that are required for cellulose biosynthesis.


    Organizational Affiliation

    Division of Biological Sciences, Graduate School of Science, Hokkaido University, Sapporo, Hokkaido 060-0810, Japan.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Probable endoglucanase
A
334Komagataeibacter hanseniiMutation(s): 0
Gene Names: cmcAX
EC: 3.2.1.4
Find proteins for P37696 (Komagataeibacter hansenii)
Go to UniProtKB:  P37696
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.176
  • Space Group: P 61
Unit Cell:
Length (Å)Angle (°)
a = 88.878α = 90.00
b = 88.878β = 90.00
c = 93.980γ = 120.00
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
SHELXDEphasing
SHELXDphasing
SHELXEmodel building
CNSrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2006-03-14
    Type: Initial release
  • Version 1.1: 2008-04-30
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
