1URX | pdb_00001urx

Crystallographic structure of beta-agarase A in complex with oligoagarose


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:
    0.182 (Depositor), 0.201 (DCC)
  • R-Value Work:
    0.155 (Depositor), 0.170 (DCC)
  • R-Value Observed:
    0.156 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 1URX

This is version 2.1 of the entry. See complete history

Literature

Parallel Substrate Binding Sites in a Beta-Agarase Suggest a Novel Mode of Action on Double-Helical Agarose

Allouch, J.Helbert, W.Henrissat, B.Czjzek, M.

(2004) Structure 12: 623

  • DOI: https://doi.org/10.1016/j.str.2004.02.020
  • Primary Citation Related Structures:
    1URX

  • PubMed Abstract:

    Agarose is a gel-forming polysaccharide with an alpha-L(1,4)-3,6-anhydro-galactose, beta-D(1,3)-galactose repeat unit, from the cell walls of marine red algae. beta-agarase A, from the Gram-negative bacterium Zobellia galactanivorans, is secreted to the external medium and degrades agarose with an endo-mechanism. The structure of the inactive mutant beta-agarase A-E147S in complex with agaro-octaose has been solved at 1.7 A resolution. Two oligosaccharide chains are bound to the protein. The first one resides in the active site channel, spanning subsites -4 to -1. A second oligosaccharide binding site, on the opposite side of the protein, was filled with eight sugar units, parallel to the active site. The crystal structure of the beta-agarase A with agaro-octaose provides detailed information on agarose recognition in the catalytic site. The presence of the second, parallel, binding site suggests that the enzyme might be able to unwind the double-helical structure of agarose prior to the catalytic cleavage.


  • Organizational Affiliation
    • Architecture et Fonction de la Macromolécules Biologiques, UMR 6098, Centre National de la Recherche Scientifique and Universités Aix-Marseille I and II, 31 chemin Joseph Aiguier, F-13402 Marseille Cedex 20, France [corrected]

Macromolecule Content

  • Total Structure Weight: 33.89 kDa
  • Atom Count: 2,642
  • Modeled Residue Count: 268
  • Deposited Residue Count: 282
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
BETA-AGARASE A282Zobellia galactanivoransMutation(s): 1
EC: 3.2.1.81
UniProt
Find proteins for G0L322 (Zobellia galactanivorans (strain DSM 12802 / CCUG 47099 / CIP 106680 / NCIMB 13871 / Dsij))
Explore G0L322
Go to UniProtKB:  G0L322
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0L322
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
3,6-anhydro-alpha-L-galactopyranose-(1-3)-beta-D-galactopyranose-(1-4)-3,6-anhydro-alpha-L-galactopyranose-(1-3)-alpha-D-galactopyranose
B
4N/A
Glycosylation Resources
GlyTouCan: G61438FI
GlyCosmos: G61438FI
Entity ID: 3
MoleculeChains Length2D Diagram GlycosylationD Interactions
3,6-anhydro-alpha-L-galactopyranose-(1-3)-beta-D-galactopyranose-(1-4)-3,6-anhydro-alpha-L-galactopyranose-(1-3)-beta-D-galactopyranose-(1-4)-3,6-anhydro-alpha-L-galactopyranose-(1-3)-beta-D-galactopyranose-(1-4)-3,6-anhydro-alpha-L-galactopyranose
C
7N/A
Glycosylation Resources
GlyTouCan: G77527TB
GlyCosmos: G77527TB

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CA

Query on CA



Download:Ideal Coordinates CCD File
D [auth A]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:  0.182 (Depositor), 0.201 (DCC)
  • R-Value Work:  0.155 (Depositor), 0.170 (DCC)
  • R-Value Observed: 0.156 (Depositor)
Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 51.38α = 90
b = 51.38β = 90
c = 205.36γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
DENZOdata reduction
SCALAdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2004-03-04
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2019-10-16
    Changes: Data collection, Derived calculations, Experimental preparation, Other
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
  • Version 2.1: 2023-12-13
    Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
