1TQG

CheA phosphotransferase domain from Thermotoga maritima


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 0.98 Å
  • R-Value Free: 0.211
  • R-Value Work: 0.179

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Helical Shifts Generate Two Distinct Conformers in the Atomic Resolution Structure of the CheA Phosphotransferase Domain from Thermotoga maritima.

Quezada, C.M.Gradinaru, C.Simon, M.I.Bilwes, A.M.Crane, B.R.

(2004) J.Mol.Biol. 341: 1283-1294

  • DOI: 10.1016/j.jmb.2004.06.061

  • PubMed Abstract:
  • Helical histidine phosphotransferase (HPt) domains play a central role in many aspects of bacterial signal transduction. The 0.98 A resolution crystallographic structure of the amino-terminal HPt domain (P1) from the chemotaxis kinase CheA of Thermot ...

    Helical histidine phosphotransferase (HPt) domains play a central role in many aspects of bacterial signal transduction. The 0.98 A resolution crystallographic structure of the amino-terminal HPt domain (P1) from the chemotaxis kinase CheA of Thermotoga maritima reveals a remarkable degree of structural heterogeneity within a four-helix bundle. Two of the four helices have alternate main-chain conformations that differ by a 1.3-1.7A shift along the bundle axis. These dual conformers were only resolved with atomic resolution diffraction data and their inclusion significantly improved refinement statistics. Neither conformer optimizes packing within the helical core, consistent with their nearly equal refined occupancies. Altered hydrogen bonding within an inter-helical loop may facilitate transition between conformers. Two discrete structural states rather than a continuum of closely related conformations indicates an energetic barrier to conversion between conformers in the crystal at 100K, although many more states are expected in solution at physiological temperatures. Anisotropic atomic thermal B factors within the two conformers indicate modest overall atomic displacement that is largest perpendicular to the helical bundle and not along the direction of apparent motion. Despite the conformational heterogeneity of P1 in the crystal at low temperature, the protein displays high thermal stability in solution (T(m)=100 degrees C). Addition of a variable C-terminal region that corresponds to a mobile helix in other CheA structures significantly narrows the temperature width of the unfolding transition and may affect domain dynamics. Helices that compose the kinase recognition site and contain the phospho-accepting His45 do not have alternate conformations. In this region, atomic resolution provides detailed structural parameters for a conserved hydrogen-bonding network that tunes the reactivity of His45. A neighboring glutamate (E67), essential for phosphotransferase activity hydrogen bonds directly to His45 N(delta1). E67 generates a negative electrostatic surface surrounding the reactive His that is conserved by most CheA kinases, but absent in related phosphotransferase proteins. The P1 conformations that we observe are likely relevant to other helical or coiled-coil proteins and may be important for generating switches in signaling processes.


    Organizational Affiliation

    Division of Biology, California Institute of Technology, Pasadena, CA 91125, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Chemotaxis protein cheA
A
105Thermotoga maritima (strain ATCC 43589 / MSB8 / DSM 3109 / JCM 10099)Mutation(s): 0
Gene Names: cheA
EC: 2.7.13.3
Find proteins for Q56310 (Thermotoga maritima (strain ATCC 43589 / MSB8 / DSM 3109 / JCM 10099))
Go to UniProtKB:  Q56310
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 0.98 Å
  • R-Value Free: 0.211
  • R-Value Work: 0.179
  • Space Group: P 2 2 21
Unit Cell:
Length (Å)Angle (°)
a = 27.381α = 90.00
b = 37.419β = 90.00
c = 87.542γ = 90.00
Software Package:
Software NamePurpose
SHELXmodel building
SHELXL-97refinement
DENZOdata reduction
SCALEPACKdata scaling
PHASESphasing
SHELXphasing
CNSrefinement
CNSphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2004-09-07
    Type: Initial release
  • Version 1.1: 2008-04-30
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2017-10-11
    Type: Refinement description
