1T68 | pdb_00001t68

Crystal structure of nitrophorin 2 complex with NO

• PDB DOI: https://doi.org/10.2210/pdb1T68/pdb

• Classification: TRANSPORT PROTEIN
• Organism(s): Rhodnius prolixus
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2004-05-05 Released: 2005-05-17
• Deposition Author(s): Weichsel, A., Montfort, W.R.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.45 Å
• R-Value Free:
  0.235 (Depositor), 0.194 (DCC)
• R-Value Work:
  0.193 (Depositor), 0.200 (DCC)
• R-Value Observed:
  0.195 (Depositor)

Starting Model: experimental

Literature

Conformational change and heme ruffling in nitrophorin 2, a nitric oxide carrier from kissing bug

Weichsel, A., Montfort, W.R.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 20.73 kDa
• Atom Count: 1,563
• Modeled Residue Count: 180
• Deposited Residue Count: 180
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Nitrophorin 2	A [auth X]	180	Rhodnius prolixus	Mutation(s): 0
UniProt
Find proteins for Q26241 (Rhodnius prolixus) Explore Q26241  Go to UniProtKB:  Q26241

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
HEM	B [auth X]	PROTOPORPHYRIN IX CONTAINING FE C34 H32 Fe N4 O4 KABFMIBPWCXCRK-RGGAHWMASA-L
NO	C [auth X]	NITRIC OXIDE N O ODUCDPQEXGNKDN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.45 Å
• R-Value Free:  0.235 (Depositor), 0.194 (DCC)
• R-Value Work:  0.193 (Depositor), 0.200 (DCC)
• R-Value Observed: 0.195 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 39.295	α = 90
b = 125.444	β = 90
c = 33.196	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
CCP4	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2005-05-17
Deposition Author(s): Weichsel, A., Montfort, W.R.

Revision History

• Version 1.0: 2005-05-17
  Type: Initial release

• Version 1.1: 2008-04-30
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Version format compliance
• Version 1.3: 2017-10-11
  Changes: Refinement description
• Version 1.4: 2023-08-23
  Changes: Data collection, Database references, Derived calculations, Refinement description
• Version 1.5: 2024-10-30
  Changes: Structure summary
