1SKF

CRYSTAL STRUCTURE OF THE STREPTOMYCES K15 DD-TRANSPEPTIDASE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.183

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

The crystal structure of a penicilloyl-serine transferase of intermediate penicillin sensitivity. The DD-transpeptidase of streptomyces K15.

Fonze, E.Vermeire, M.Nguyen-Disteche, M.Brasseur, R.Charlier, P.

(1999) J.Biol.Chem. 274: 21853-21860

  • DOI: 10.1074/jbc.274.31.21853

  • PubMed Abstract:
  • The serine DD-transpeptidase/penicillin-binding protein of Streptomyces K15 catalyzes peptide bond formation in a way that mimics the penicillin-sensitive peptide cross-linking reaction involved in bacterial cell wall peptidoglycan assembly. The Stre ...

    The serine DD-transpeptidase/penicillin-binding protein of Streptomyces K15 catalyzes peptide bond formation in a way that mimics the penicillin-sensitive peptide cross-linking reaction involved in bacterial cell wall peptidoglycan assembly. The Streptomyces K15 enzyme is peculiar in that it can be considered as an intermediate between classical penicillin-binding proteins, for which benzylpenicillin is a very efficient inactivator, and the resistant penicillin-binding proteins that have a low penicillin affinity. With its moderate penicillin sensitivity, the Streptomyces K15 DD-transpeptidase would be helpful in the understanding of the structure-activity relationship of this penicillin-recognizing protein superfamily. The structure of the Streptomyces K15 enzyme has been determined by x-ray crystallography at 2.0-A resolution and refined to an R-factor of 18.6%. The fold adopted by this 262-amino acid polypeptide generates a two-domain structure that is close to those of class A beta-lactamases. However, the Streptomyces K15 enzyme has two particular structural features. It lacks the amino-terminal alpha-helix found in the other penicilloyl-serine transferases, and it exhibits, at its surface, an additional four-stranded beta-sheet. These two characteristics might serve to anchor the enzyme in the plasma membrane. The overall topology of the catalytic pocket of the Streptomyces K15 enzyme is also comparable to that of the class A beta-lactamases, except that the Omega-loop, which bears the essential catalytic Glu(166) residue in the class A beta-lactamases, is entirely modified. This loop adopts a conformation similar to those found in the Streptomyces R61 DD-carboxypeptidase and class C beta-lactamases, with no equivalent acidic residue.


    Related Citations:
    • Crystallization and X-Ray Diffraction Study of the Streptomyces K15 Penicillin-Binding Dd-Transpeptidase
      Englebert, S.,Charlier, P.,Fonze, E.,To'Th, Y.,Vermeire, M.,Van Beeumen, J.,Grandchamps, J.,Hoffmann, K.,Leyh-Bouille, M.,Nguyen-Disteche, M.,Ghuysen, J.-M.
      (1994) J.Mol.Biol. 241: 295


    Organizational Affiliation

    Centre d'Ingénierie des Protéines, Université de Liège, Institut de Physique, B5, Sart Tilman B-4000, Belgium. Eveline.Fonze@ulg.ac.be




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
D-ALANYL-D-ALANINE TRANSPEPTIDASE
A
262Streptomyces sp. (strain K15)Mutation(s): 0
EC: 3.4.16.4
Find proteins for P39042 (Streptomyces sp. (strain K15))
Go to UniProtKB:  P39042
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.183
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 46.593α = 90.00
b = 54.528β = 90.00
c = 108.697γ = 90.00
Software Package:
Software NamePurpose
X-PLORphasing
X-PLORmodel building
X-PLORrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 1999-08-20
    Type: Initial release
  • Version 1.1: 2008-03-24
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Source and taxonomy, Version format compliance
