1SBW

CRYSTAL STRUCTURE OF MUNG BEAN INHIBITOR LYSINE ACTIVE FRAGMENT COMPLEX WITH BOVINE BETA-TRYPSIN AT 1.8A RESOLUTION


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.196
  • R-Value Work: 0.164

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Crystal structure of mung bean inhibitor lysine active fragment complex with bovine beta-trypsin at 1.8A resolution.

Zhu, Y.Huang, Q.Chi, C.

(1999) J.Biomol.Struct.Dyn. 16: 1219-1224

  • DOI: 10.1080/07391102.1999.10508329

  • PubMed Abstract:
  • The crystal structure of the complex of mung bean inhibitor lysine active fragment with bovine beta-trypsin has been determined by X-ray crystallographic analysis at a resolution of 1.8 A. Refinement of the model of the complex converged at a final R ...

    The crystal structure of the complex of mung bean inhibitor lysine active fragment with bovine beta-trypsin has been determined by X-ray crystallographic analysis at a resolution of 1.8 A. Refinement of the model of the complex converged at a final R value of 0.16. From the resulting electron density map, about one-third of the residues of the inhibitor were identified and two residues, at position P4 and P2' respectively, were found to be inconsistent with the sequence reported previously. The peptide chain of the inhibitor at the trypsin active site turns back sharply at Pro23I and forms a 9-residue reactive loop, which interacts with trypsin in a similar manner to the other families of inhibitors, suggesting an important and common role of these regions in exhibiting inhibitory activity.


    Organizational Affiliation

    Department of Chemistry, Peking University, Beijing, PR China.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
PROTEIN (BETA-TRYPSIN)
A
223Bos taurusEC: 3.4.21.4
Find proteins for P00760 (Bos taurus)
Go to UniProtKB:  P00760
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
PROTEIN (MUNG BEAN INHIBITOR LYSIN ACTIVE FRAGMENT)
I
35Vigna radiata var. radiataN/A
Find proteins for P01062 (Vigna radiata var. radiata)
Go to UniProtKB:  P01062
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
CA
Query on CA

Download SDF File
Download CCD File
A
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.196
  • R-Value Work: 0.164
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 63.270α = 90.00
b = 63.550β = 90.00
c = 69.440γ = 90.00
Software Package:
Software NamePurpose
X-PLORrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 1999-05-06
    Type: Initial release
  • Version 1.1: 2008-04-26
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
