Biological Assembly 1

 3D View: Structure | 1D-3D View | Validation Report

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 1.20 kDa
• Atom Count: 85
• Modelled Residue Count: 11
• Deposited Residue Count: 11
• Unique protein chains: 1

1RVS

STRUCTURE OF TRANSTHYRETIN IN AMYLOID FIBRILS DETERMINED BY SOLID-STATE MAGIC ANGLE SPINNING NMR

• PDB DOI: 10.2210/pdb1RVS/pdb

• Classification: DE NOVO PROTEIN
• Organism(s): Rattus norvegicus
• Mutation(s): No


• Deposited: 2003-12-14 Released: 2004-01-20
• Deposition Author(s): Jaroniec, C.P., Macphee, C.E., Bajaj, V.S., Mcmahon, M.T., Dobson, C.M., Griffin, R.G.

---

Experimental Data Snapshot

• Method: SOLID-STATE NMR
• Conformers Calculated: 20
• Conformers Submitted: 20
• Selection Criteria: structures with the least restraint violations

Literature

High-resolution molecular structure of a peptide in an amyloid fibril determined by magic angle spinning NMR spectroscopy

Jaroniec, C.P., MacPhee, C.E., Bajaj, V.S., McMahon, M.T., Dobson, C.M., Griffin, R.G.

(2004) Proc Natl Acad Sci U S A 101: 711-716

• PubMed: 14715898
• DOI: 10.1073/pnas.0304849101
• Primary Citation of Related Structures:
  1RVS


• PubMed Abstract:


Amyloid fibrils are self-assembled filamentous structures associated with protein deposition conditions including Alzheimer's disease and the transmissible spongiform encephalopathies. Despite the immense medical importance of amyloid fibrils, no atomic-resolution structures are available for these materials, because the intact fibrils are insoluble and do not form diffraction-quality 3D crystals. Here we report the high-resolution structure of a peptide fragment of the amyloidogenic protein transthyretin, TTR(105-115), in its fibrillar form, determined by magic angle spinning NMR spectroscopy. The structure resolves not only the backbone fold but also the precise conformation of the side chains. Nearly complete (13)C and (15)N resonance assignments for TTR(105-115) formed the basis for the extraction of a set of distance and dihedral angle restraints. A total of 76 self-consistent experimental measurements, including 41 restraints on 19 backbone dihedral angles and 35 (13)C-(15)N distances between 3 and 6 A were obtained from 2D and 3D NMR spectra recorded on three fibril samples uniformly (13)C, (15)N-labeled in consecutive stretches of four amino acids and used to calculate an ensemble of peptide structures. Our results indicate that TTR(105-115) adopts an extended beta-strand conformation in the amyloid fibrils such that both the main- and side-chain torsion angles are close to their optimal values. Moreover, the structure of this peptide in the fibrillar form has a degree of long-range order that is generally associated only with crystalline materials. These findings provide an explanation of the unusual stability and characteristic properties of this form of polypeptide assembly.

---

Related Citations:

• Molecular Conformation of a Peptide Fragment of Transthyretin in an Amyloid Fibril
  Jaroniec, C.P., MacPhee, C.E., Astrof, N.S., Dobson, C.M., Griffin, R.G.
  (2002) Proc Natl Acad Sci U S A 99: 16748

---

Organizational Affiliation:

Department of Chemistry and Center for Magnetic Resonance, Francis Bitter Magnet Laboratory, Massachusetts Institute of Technology, Cambridge, MA 02139, USA.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Transthyretin	A	11	Rattus norvegicus	Mutation(s): 0  Gene Names: Ttr, Tt
UniProt
Find proteins for P02767 (Rattus norvegicus) Explore P02767  Go to UniProtKB:  P02767

Experimental Data & Validation

Experimental Data

• Method: SOLID-STATE NMR
• Conformers Calculated: 20
• Conformers Submitted: 20
• Selection Criteria: structures with the least restraint violations
• OLDERADO: 1RVS Olderado

Structure Validation

Entry History

Deposition Data

• Deposited Date: 2003-12-14
• Released Date: 2004-01-20
Deposition Author(s): Jaroniec, C.P., Macphee, C.E., Bajaj, V.S., Mcmahon, M.T., Dobson, C.M., Griffin, R.G.

Revision History

• Version 1.0: 2004-01-20
  Type: Initial release

• Version 1.1: 2008-04-29
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Version format compliance
• Version 1.3: 2021-07-07
  Changes: Data collection, Derived calculations, Source and taxonomy
