1RHI

HUMAN RHINOVIRUS 3 COAT PROTEIN

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.288
  • R-Value Work: 0.284
  • R-Value Observed: 0.284

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history.


Literature

Human rhinovirus 3 at 3.0 A resolution.

Zhao, R., Pevear, D.C., Kremer, M.J., Giranda, V.L., Kofron, J.A., Kuhn, R.J., Rossmann, M.G.

(1996) Structure 4: 1205-1220

  • DOI: 10.1016/s0969-2126(96)00128-1
  • Primary Citation of Related Structures:
    1RHI

  • PubMed Abstract:

    • The over 100 serotypes of human rhinoviruses (HRV) are major causative agents of the common cold in humans. These HRVs can be roughly divided into a major and minor group according to their cellular receptors. They can also be divided into two antiviral groups, A and B, based on their sensitivity to different capsid-binding antiviral compounds ...

    The over 100 serotypes of human rhinoviruses (HRV) are major causative agents of the common cold in humans. These HRVs can be roughly divided into a major and minor group according to their cellular receptors. They can also be divided into two antiviral groups, A and B, based on their sensitivity to different capsid-binding antiviral compounds. The crystal structures of HRV14 and HRV16, major-receptor group rhinoviruses, as well as HRV1A, a minor-receptor group rhinovirus, were determined previously. Sequence comparisons had shown that HRV14 seemed to be an outlier among rhinoviruses. Furthermore, HRV14 was the only virus with no cellular 'pocket factor' in a hydrophobic pocket which is targeted by many capsid-binding antiviral compounds and is thought to regulate viral stability. HRV3, another major-receptor group virus, was chosen for study because it is one of a subset of serotypes that best represents the drug sensitivity of most rhinovirus serotypes. Both HRV3 and HRV14 belong to antiviral group A, while HRV16 and HRV1A belong to antiviral group B.

    Related Citations:
    • Viral Cell Recognition and Entry
      Rossmann, M.G.
      (1994) Protein Sci 3: 1712
    • A Comparison of the Anti-Rhinoviral Drug Binding Pocket in Hrv14 and Hrv1A
      Kim, K.H., Willingmann, P., Gong, Z.X., Kremer, M.J., Chapman, M.S., Minor, I., Oliveira, M.A., Rossmann, M.G., Andries, K., Diana, G.D., al., et
      (1993) J Mol Biol 230: 206
    • The Structure of Human Rhinovirus 16
      Oliveira, M.A., Zhao, R., Lee, W.M., Kremer, M.J., Minor, I., Rueckert, R.R., Diana, G.D., Pevear, D.C., Dutko, F.J., Mckinlay, M.A., al., et
      (1993) Structure 1: 51
    • Crystal Structure of Human Rhinovirus Serotype 1A (Hrv1A)
      Kim, S.S., Smith, T.J., Chapman, M.S., Rossmann, M.C., Pevear, D.C., Dutko, F.J., Felock, P.J., Diana, G.D., Mckinlay, M.A.
      (1989) J Mol Biol 210: 91
    • Structure of a Human Common Cold Virus and Functional Relationship to Other Picornaviruses
      Rossmann, M.G., Arnold, E., Erickson, J.W., Frankenberger, E.A., Griffith, J.P., Hecht, H.J., Johnson, J.E., Kamer, G., Luo, M., Mosser, A.G., al., et
      (1985) Nature 317: 145
    Organizational Affiliation:

    Department of Biological Sciences, Purdue University, West Lafayette, IN 47907-1392, USA.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
HUMAN RHINOVIRUS 3 COAT PROTEINA [auth 1]288rhinovirus B3Mutation(s): 0
EC: 3.4.22.29 (UniProt), 3.6.1.15 (UniProt), 3.4.22.28 (UniProt), 2.7.7.48 (UniProt)
UniProt
Find proteins for Q82081 (Human rhinovirus 3)
Explore Q82081
Go to UniProtKB:  Q82081
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ82081
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
HUMAN RHINOVIRUS 3 COAT PROTEINB [auth 2]262rhinovirus B3Mutation(s): 0
EC: 3.4.22.29 (UniProt), 3.6.1.15 (UniProt), 3.4.22.28 (UniProt), 2.7.7.48 (UniProt)
UniProt
Find proteins for Q82081 (Human rhinovirus 3)
Explore Q82081
Go to UniProtKB:  Q82081
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ82081
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
HUMAN RHINOVIRUS 3 COAT PROTEINC [auth 3]236rhinovirus B3Mutation(s): 0
EC: 3.4.22.29 (UniProt), 3.6.1.15 (UniProt), 3.4.22.28 (UniProt), 2.7.7.48 (UniProt)
UniProt
Find proteins for Q82081 (Human rhinovirus 3)
Explore Q82081
Go to UniProtKB:  Q82081
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ82081
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
HUMAN RHINOVIRUS 3 COAT PROTEIND [auth 4]68rhinovirus B3Mutation(s): 0
EC: 3.4.22.29 (UniProt), 3.6.1.15 (UniProt), 3.4.22.28 (UniProt), 2.7.7.48 (UniProt)
UniProt
Find proteins for Q82081 (Human rhinovirus 3)
Explore Q82081
Go to UniProtKB:  Q82081
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ82081
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CA
Query on CA
Download Ideal Coordinates CCD File
E [auth 1]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.288
  • R-Value Work: 0.284
  • R-Value Observed: 0.284
  • Space Group: P 21 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 397.9α = 90
b = 341.8β = 90
c = 301.7γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
X-PLORrefinement
MGROSCdata reduction
MGRSCLdata scaling
X-PLORphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1997-03-12
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2012-05-16
    Changes: Advisory
