1R7M | pdb_00001r7m

The homing endonuclease I-SceI bound to its DNA recognition region


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.25 Å
  • R-Value Free:
    0.267 (Depositor), 0.265 (DCC)
  • R-Value Work:
    0.235 (Depositor), 0.233 (DCC)
  • R-Value Observed:
    0.235 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1R7M

This is version 1.3 of the entry. See complete history

Literature

The crystal structure of the gene targeting homing endonuclease I-SceI reveals the origins of its target site specificity

Moure, C.M.Gimble, F.S.Quiocho, F.A.

(2003) J Mol Biology 334: 685-695

  • DOI: https://doi.org/10.1016/j.jmb.2003.09.068
  • Primary Citation Related Structures:
    1R7M

  • PubMed Abstract:

    The I-SceI homing endonuclease enhances gene targeting by introducing double-strand breaks at specific chromosomal loci, thereby increasing the recombination frequency. Here, we report the crystal structure of the enzyme complexed to its DNA substrate and Ca(2+) determined at 2.25A resolution. The structure shows the prototypical beta-saddle of LAGLIDADG homing endonucleases that is contributed by two pseudo-symmetric domains. The high specificity of I-SceI is explained by the large number of protein-DNA contacts, many that are made by a long beta-hairpin loop that reaches into the major groove of the DNA. The DNA minor groove is compressed at the catalytic center, bringing the two scissile phosphodiester bonds into close proximity. The protein-Ca(2+)-DNA structure shows the protein bound to its DNA substrate in a pre-reactive state that is defined by the presence of two asymmetric active sites, one of which appears poised to first cleave the DNA bottom strand.


  • Organizational Affiliation
    • Howard Hughes Medical Institute, Baylor College of Medicine, Houston, TX 77030, USA.

Macromolecule Content

  • Total Structure Weight: 86.39 kDa
  • Atom Count: 5,883
  • Modeled Residue Count: 542
  • Deposited Residue Count: 570
  • Unique protein chains: 1
  • Unique nucleic acid chains: 2

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Intron-encoded endonuclease I-SceIE [auth A],
F [auth B]
235Saccharomyces cerevisiaeMutation(s): 0
Gene Names: SECY
EC: 3.1
UniProt
Find proteins for P03882 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P03882
Go to UniProtKB:  P03882
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03882
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 1
MoleculeChains LengthOrganismImage
5'-D(*CP*AP*CP*GP*CP*TP*AP*GP*GP*GP*AP*TP*AP*AP*CP*AP*GP*GP*GP*TP*AP*AP*TP*AP*C)-3'A [auth C],
C [auth E]
25N/A
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
5'-D(*GP*GP*TP*AP*TP*TP*AP*CP*CP*CP*TP*GP*TP*TP*AP*TP*CP*CP*CP*TP*AP*GP*CP*GP*T)-3'B [auth D],
D [auth F]
25N/A
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.25 Å
  • R-Value Free:  0.267 (Depositor), 0.265 (DCC)
  • R-Value Work:  0.235 (Depositor), 0.233 (DCC)
  • R-Value Observed: 0.235 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 80.6α = 90
b = 90.7β = 90
c = 115.3γ = 90
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data reduction
SCALEPACKdata scaling
SHARPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2004-10-26
    Type: Initial release
  • Version 1.1: 2008-04-29
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-02-14
    Changes: Data collection, Database references, Derived calculations
