1R09

HUMAN RHINOVIRUS 14 COMPLEXED WITH ANTIVIRAL COMPOUND R 61837


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Human rhinovirus 14 complexed with antiviral compound R 61837.

Chapman, M.S.Minor, I.Rossmann, M.G.Diana, G.D.Andries, K.

(1991) J Mol Biol 217: 455-463

  • DOI: 10.1016/0022-2836(91)90749-v
  • Primary Citation of Related Structures:
    1R09

  • PubMed Abstract:
  • The binding of the antirhinoviral agent R 61837 to human rhinovirus 14 has been examined by X-ray crystallographic methods. The compound R 61837 binds in the same pocket (underneath the canyon floor) as the "WIN" antirhinoviral agents. It does not penetrate as far into the pocket but causes similar conformational changes in the virus capsid ...

    The binding of the antirhinoviral agent R 61837 to human rhinovirus 14 has been examined by X-ray crystallographic methods. The compound R 61837 binds in the same pocket (underneath the canyon floor) as the "WIN" antirhinoviral agents. It does not penetrate as far into the pocket but causes similar conformational changes in the virus capsid. The movement of residues 1217 to 1221 of viral protein 1 (in the "FMDV loop") is more pronounced for R 61837 than for WIN compounds. Although both R 61837 and WIN antiviral agents partially fill the same hydrophobic pocket, atomic binding interactions differ, showing that considerable diversity in the nature of antiviral agents is possible.


    Related Citations:
    • Analysis of the Structure of a Common Cold Virus, Human Rhinovirus 14, Refined at a Resolution of 3.0 Angstroms
      Arnold, E., Rossman, M.G.
      (1990) J Mol Biol 211: 763
    • Structural Analysis of Antiviral Agents that Interact with the Capsid of Human Rhinoviruses
      Badger, J., Minor, I., Oliveira, M.A., Smith, T.J., Rossmann, M.G.
      (1989) Proteins 6: 1
    • Three-Dimensional Structures of Drug-Resistant Mutants of Human Rhinovirus 14
      Badger, J., Krishnaswamy, S., Kremer, M.J., Oliveira, M.A., Rossmann, M.G., Heinz, B.A., Rueckert, R.R., Dutko, F.J., Mckinlay, M.A.
      (1989) J Mol Biol 207: 163
    • The Use of Molecular Replacement Phases for the Refinement of the Human Rhinovirus 14 Structure
      Arnold, E., Rossmann, M.G.
      (1988) Acta Crystallogr A 44: 270
    • Structural Analysis of a Series of Antiviral Agents Complexed with Human Rhinovirus 14
      Badger, J., Minor, I., Kremer, M.J., Oliveira, M.A., Smith, T.J., Griffith, J.P., Guerin, D.M.A., Krishnaswamy, S., Luo, M., Rossmann, M.G., Mckinlay, M.A., Diana, G.D., Dutko, F.J., Fancher, M., Rueckert, R.R., Heinz, B.A.
      (1988) Proc Natl Acad Sci U S A 85: 3304
    • The Structure Determination of a Common Cold Virus, Human Rhinovirus 14
      Arnold, E., Vriend, G., Luo, M., Griffith, J.P., Kamer, G., Erickson, J.W., Johnson, J.E., Rossmann, M.G.
      (1987) Acta Crystallogr A 43: 346
    • Implications of the Picornavirus Capsid Structure for Polyprotein Structure
      Arnold, E., Luo, M., Vriend, G., Rossmann, M.G., Palmenberg, A.C., Parks, G.D., Nicklin, M.J.H., Wimmer, E.
      (1987) Proc Natl Acad Sci U S A 84: 21
    • The Site of Attachment in Human Rhinovirus 14 for Antiviral Agents that Inhibit Uncoating
      Smith, T.J., Kremer, M.J., Luo, M., Vriend, G., Arnold, E., Kamer, G., Rossmann, M.G., Mckinlay, M.A., Diana, G.D., Otto, M.J.
      (1986) Science 233: 1286
    • The Structure of a Human Common Cold Virus (Rhinovirus 14) and its Evolutionary Relations to Other Viruses
      Rossmann, M.G., Arnold, E., Erickson, J.W., Frankenberger, E.A., Griffith, J.P., Hecht, H.-J., Johnson, J.E., Kamer, G., Luo, M., Vriend, G.
      (1987) Chem Scr 26: 313
    • Structure of a Human Common Cold Virus and Functional Relationship to Other Picornaviruses
      Rossmann, M.G., Arnold, E., Erickson, J.W., Frankenberger, E.A., Griffith, J.P., Hecht, H.-J., Johnson, J.E., Kamer, G., Luo, M., Mosser, A.G., Rueckert, R.R., Sherry, B., Vriend, G.
      (1985) Nature 317: 145
    • Virion Orientation in Cubic Crystals of the Human Common Cold Virus Hrv14
      Arnold, E., Erickson, J.W., Fout, G.S., Frankenberger, E.A., Hecht, H.-J., Luo, M., Rossmann, M.G., Rueckert, R.R.
      (1984) J Mol Biol 177: 417
    • Picornaviruses of Two Different Genera Have Similar Structures
      Luo, M., Arnold, E., Erickson, J.W., Rossmann, M.G., Boege, U., Scraba, D.G.
      (1984) J Mol Biol 180: 703
    • Crystallization of a Common Cold Virus, Human Rhinovirus 14. (Quote)Isomorphism(Quote) with Poliovirus Crystals
      Erickson, J.W., Frankenberger, E.A., Rossmann, M.G., Fout, G.S., Medappa, K.C., Rueckert, R.R.
      (1983) Proc Natl Acad Sci U S A 80: 931

    Organizational Affiliation

    Department of Biological Sciences, Purdue University, West Lafayette, IN 47907.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
HUMAN RHINOVIRUS 14 COAT PROTEIN (SUBUNIT VP1)A [auth 1]289Rhinovirus B14Mutation(s): 0
EC: 3.4.22.29 (UniProt), 3.6.1.15 (UniProt), 3.4.22.28 (UniProt), 2.7.7.48 (UniProt)
UniProt
Find proteins for P03303 (Human rhinovirus 14)
Explore P03303
Go to UniProtKB:  P03303
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
HUMAN RHINOVIRUS 14 COAT PROTEIN (SUBUNIT VP2)B [auth 2]262Rhinovirus B14Mutation(s): 0
EC: 3.4.22.29 (UniProt), 3.6.1.15 (UniProt), 3.4.22.28 (UniProt), 2.7.7.48 (UniProt)
UniProt
Find proteins for P03303 (Human rhinovirus 14)
Explore P03303
Go to UniProtKB:  P03303
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
HUMAN RHINOVIRUS 14 COAT PROTEIN (SUBUNIT VP3)C [auth 3]236Rhinovirus B14Mutation(s): 0
EC: 3.4.22.29 (UniProt), 3.6.1.15 (UniProt), 3.4.22.28 (UniProt), 2.7.7.48 (UniProt)
UniProt
Find proteins for P03303 (Human rhinovirus 14)
Explore P03303
Go to UniProtKB:  P03303
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
HUMAN RHINOVIRUS 14 COAT PROTEIN (SUBUNIT VP4)D [auth 4]68Rhinovirus B14Mutation(s): 0
EC: 3.4.22.29 (UniProt), 3.6.1.15 (UniProt), 3.4.22.28 (UniProt), 2.7.7.48 (UniProt)
UniProt
Find proteins for P03303 (Human rhinovirus 14)
Explore P03303
Go to UniProtKB:  P03303
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
JEN
Query on JEN

Download Ideal Coordinates CCD File
E [auth 1]3-METHOXY-6-[4-(3-METHYLPHENYL)-1-PIPERAZINYL]PYRIDAZINE
C16 H20 N4 O
DDOAUTHWSCUHQA-UHFFFAOYSA-N
 Ligand Interaction
DMS
Query on DMS

Download Ideal Coordinates CCD File
F [auth 1]DIMETHYL SULFOXIDE
C2 H6 O S
IAZDPXIOMUYVGZ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • Space Group: P 21 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 445.1α = 90
b = 445.1β = 90
c = 445.1γ = 90

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1991-10-15
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
