1PBH | pdb_00001pbh

CRYSTAL STRUCTURE OF HUMAN RECOMBINANT PROCATHEPSIN B AT 3.2 ANGSTROM RESOLUTION

• PDB DOI: https://doi.org/10.2210/pdb1PBH/pdb

• Classification: THIOL PROTEASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 1997-02-14 Released: 1998-02-25
• Deposition Author(s): Podobnik, M., Turk, D.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 3.20 Å
• R-Value Free:
  0.252 (Depositor)
• R-Value Work:
  0.216 (Depositor)

Starting Model: experimental

Literature

Crystal structures of human procathepsin B at 3.2 and 3.3 Angstroms resolution reveal an interaction motif between a papain-like cysteine protease and its propeptide.

Turk, D., Podobnik, M., Kuhelj, R., Dolinar, M., Turk, V.

(1996) FEBS Lett 384: 211-214

• PubMed: 8617355
• DOI: https://doi.org/10.1016/0014-5793(96)00309-2
• Primary Citation Related Structures:
  1PBH, 2PBH


• PubMed Abstract:


  A wild-type human procathepsin B was expressed, crystallized in two crystal forms and its crystal structure determined at 3.2 and 3.3 Angstroms resolution. The structure reveals that the propeptide folds on the cathepsin B surface, shielding the enzyme active site from exposure to solvent. The structure of the enzymatically active domains is virtually identical to that of the native enzyme [Musil et al. (1991) EMBO J. 10, 2321-2330]: the main difference is that the occluding loop residues are lifted above the body of the mature enzyme, supporting the propeptide structure.

---

Organizational Affiliation:
• Dept of Biochem. and Mol. Biol. Jozef Stefan Institute, Ljubljana, Slovenia.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 35.23 kDa
• Atom Count: 2,470
• Modeled Residue Count: 317
• Deposited Residue Count: 317
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
PROCATHEPSIN B	A	317	Homo sapiens	Mutation(s): 0  EC: 3.4.22.1
UniProt & NIH Common Fund Data Resources
Find proteins for P07858 (Homo sapiens) Explore P07858  Go to UniProtKB:  P07858
PHAROS:  P07858 GTEx:  ENSG00000164733

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 3.20 Å
• R-Value Free:  0.252 (Depositor)
• R-Value Work:  0.216 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 44.95	α = 90
b = 77.1	β = 90
c = 97.33	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
CCP4	data reduction
MAIN	model building
MAIN	refinement
CCP4	data scaling
MAIN	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 1998-02-25
Deposition Author(s): Podobnik, M., Turk, D.

Revision History

• Version 1.0: 1998-02-25
  Type: Initial release

• Version 1.1: 2008-03-24
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Version format compliance
• Version 1.3: 2023-08-09
  Changes: Database references, Refinement description
• Version 1.4: 2024-10-30
  Changes: Data collection, Structure summary
