1OJL | pdb_00001ojl

Crystal structure of a sigma54-activator suggests the mechanism for the conformational switch necessary for sigma54 binding

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:
    0.308 (Depositor), 0.371 (DCC)
  • R-Value Work:
    0.252 (Depositor)
  • R-Value Observed:
    0.255 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1OJL

Ligand Structure Quality Assessment


This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of the central and C-terminal domain of the sigma(54)-activator ZraR.

Sallai, L., Tucker, P.A.

(2005) J Struct Biol 151: 160-170

  • DOI: https://doi.org/10.1016/j.jsb.2005.05.006
  • Primary Citation Related Structures:
    1OJL

  • PubMed Abstract:

    The sigma(54)-dependent transcription in bacteria is associated with various stress and growth conditions. Activators of the sigma(54) protein contain a central domain belonging to the AAA+ superfamily of ATPases, members of which function in diverse cellular processes in both prokaryotic and eukaryotic cells. We describe the X-ray structure of an N-terminal domain deletion of the ZraR protein from Salmonella typhimurium, which is a homologue of the general nitrogen regulatory protein NtrC, at 3A resolution. The structure reveals a hexameric ring that is typical for AAA+ containing proteins but which differs from the heptameric ring found in the crystal structure of the AAA+ domain of NtrC1 from Aquifex aeolicus. The dimerisation interface between DNA-binding domains observed in the crystal structure suggests that dodecamers, rather than hexamers, might be the functionally important oligomer.

    • Organizational Affiliation:
    • European Molecular Biology Laboratory Hamburg Outstation, c/o DESY, Notkestrasse 85, D-22603 Hamburg, Germany.

Macromolecule Content

  • Total Structure Weight: 203.41 kDa
  • Atom Count: 12,594
  • Modeled Residue Count: 1,624
  • Deposited Residue Count: 1,824
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:
|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
TRANSCRIPTIONAL REGULATORY PROTEIN ZRAR
A, B, C, D, E
A, B, C, D, E, F
304Salmonella enterica subsp. enterica serovar TyphimuriumMutation(s): 0
UniProt
Find proteins for P25852 (Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720))
Explore P25852
Go to UniProtKB:  P25852
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25852
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:  0.308 (Depositor), 0.371 (DCC)
  • R-Value Work:  0.252 (Depositor)
  • R-Value Observed: 0.255 (Depositor)
Space Group: P 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 107.44α = 90
b = 114.74β = 90
c = 187.26γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
SHELXDphasing
SOLVEphasing
REFMACrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-05-19
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2018-06-13
    Changes: Data collection, Database references
  • Version 1.4: 2019-05-08
    Changes: Data collection, Experimental preparation
  • Version 1.5: 2024-05-08
    Changes: Data collection, Database references, Other
