Experimental Data Snapshot

  • Resolution: 1.9 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.202

wwPDB Validation 3D Report Full Report

This is version 1.4 of the entry. See complete history


Crystal structure of Escherichia coli phosphoenolpyruvate carboxykinase: a new structural family with the P-loop nucleoside triphosphate hydrolase fold.

Matte, A.Goldie, H.Sweet, R.M.Delbaere, L.T.

(1996) J.Mol.Biol. 256: 126-143

  • DOI: 10.1006/jmbi.1996.0072

  • PubMed Abstract:
  • The crystal structure of ATP-dependent phosphoenolpyruvate carboxykinase (ATP-oxaloacetate carboxy-lyase, (transphosphorylating), E.C.; PCK) from Escherichia coli strain K12 has been determined using a combination of multiple isomorphous rep ...

    The crystal structure of ATP-dependent phosphoenolpyruvate carboxykinase (ATP-oxaloacetate carboxy-lyase, (transphosphorylating), E.C.; PCK) from Escherichia coli strain K12 has been determined using a combination of multiple isomorphous replacement, density modification, and partial model phase combination, and refined to a conventional R-index of 0.204 (Rfree = 0.244) at 1.9 A resolution. Each PCK molecule consists of a 275 residue N-terminal domain and 265 residue C-terminal or mononucleotide-binding domain, with the active site postulated to be within a cleft between the two domains. PCK is an open-faced, mixed alpha/beta protein, with each domain having an alpha/beta folding topology as found in several other mononucleoside-binding enzymes. The putative phosphate-binding site of ATP adopts the P-loop motif common to many ATP and GTP-binding proteins, and is similar in structure to that found within adenylate kinase. However, the beta-sheet topology within the mononucleotide-binding fold of PCK differs from all other families within the P-loop containing nucleoside triphosphate hydrolase superfamily, therefore suggesting it represents the first member in a new family of such proteins. The mononucleotide-binding domain is also different in structure compared to the classical mononucleotide-binding fold (CMBF) common to adenylate kinase, p21ras, and elongation factor-Tu. Several amino acid residues, including R65, K212, K213, H232, K254, D269, K288 and R333 appear to make up the active site of the enzyme, and are found to be absolutely conserved among known members of the ATP-dependent PCK family. A cysteine residue is located near the active-site, as has been suggested for other PCKs, although in the E. coli enzyme C233 is buried and so is most likely not involved in substrate binding or catalysis. Two binding sites of the calcium-analog TB3+ have been determined, one within the active site coordinating to the side-chain of D269, and the other within the C-terminal domain coordinating to the side-chains of E508 and E511.

    Related Citations:
    • Sequence of the Pcka Gene of Escherichia Coli K-12: Relevance to Genetic and Allosteric Regulation and Homology of E. Coli Phosphoenolpyruvate Carboxykinase with the Enzymes from Trypanosoma Brucei and Saccharomyces Cerevisiae
      Medina, V.,Pontarollo, R.,Glaeske, D.,Tabel, H.,Goldie, H.
      (1990) J.Bacteriol. 172: 7151
    • Reactivity of Cysteinyl, Arginyl, and Lysyl Residues of Escherichia Coli Phosphoenolpyruvate Carboxykinase Against Group-Specific Chemical Reagents
      Bazaes, S.,Silva, R.,Goldie, H.,Cardemil, E.,Jabalquinto, A.M.
      (1993) J.Protein Chem. 12: 571
    • Crystallization of the Calcium-Activated Phosphoenolpyruvate Carboxykinase from Escherichia Coli K12
      Delbaere, L.T.,Vandonselaar, M.,Glaeske, D.,Jabs, C.,Goldie, H.
      (1991) J.Mol.Biol. 219: 593
    • Allosteric Control by Calcium and Mechanism of Desensitization of Phosphoenolpyruvate Carboxykinase of Escherichia Coli
      Goldie, H.,Sanwal, B.D.
      (1980) J.Biol.Chem. 255: 1399

    Organizational Affiliation

    Department of Biochemistry, University of Saskatchewan Saskatoon, Canada.


Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
540Escherichia coli (strain K12)Mutation(s): 0
Gene Names: pckA (pck)
Find proteins for P22259 (Escherichia coli (strain K12))
Go to UniProtKB:  P22259
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
Query on ACT

Download SDF File
Download CCD File
C2 H3 O2
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Resolution: 1.9 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.202
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 77.696α = 90.00
b = 89.660β = 90.00
c = 93.836γ = 90.00
Software Package:
Software NamePurpose
X-PLORmodel building
MADNESdata reduction
PROCORdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots

Entry History

Deposition Data

Revision History

  • Version 1.0: 1996-11-08
    Type: Initial release
  • Version 1.1: 2008-03-24
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Source and taxonomy, Version format compliance
  • Version 1.3: 2017-11-29
    Type: Derived calculations, Other
  • Version 1.4: 2018-04-18
    Type: Data collection
