1NRK

YGFZ PROTEIN


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.193

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Crystal structure of the YgfZ protein from Escherichia coli suggests a folate-dependent regulatory role in one-carbon metabolism.

Teplyakov, A.Obmolova, G.Sarikaya, E.Pullalarevu, S.Krajewski, W.Galkin, A.Howard, A.J.Herzberg, O.Gilliland, G.L.

(2004) J.Bacteriol. 186: 7134-7140

  • DOI: 10.1128/JB.186.21.7134-7140.2004

  • PubMed Abstract:
  • The ygfZ gene product of Escherichia coli represents a large protein family conserved in bacteria to eukaryotes. The members of this family are uncharacterized proteins with marginal sequence similarity to the T-protein (aminomethyltransferase) of th ...

    The ygfZ gene product of Escherichia coli represents a large protein family conserved in bacteria to eukaryotes. The members of this family are uncharacterized proteins with marginal sequence similarity to the T-protein (aminomethyltransferase) of the glycine cleavage system. To assist with the functional assignment of the YgfZ family, the crystal structure of the E. coli protein was determined by multiwavelength anomalous diffraction. The protein molecule has a three-domain architecture with a central hydrophobic channel. The structure is very similar to that of bacterial dimethylglycine oxidase, an enzyme of the glycine betaine pathway and a homolog of the T-protein. Based on structural superposition, a folate-binding site was identified in the central channel of YgfZ, and the ability of YgfZ to bind folate derivatives was confirmed experimentally. However, in contrast to dimethylglycine oxidase and T-protein, the YgfZ family lacks amino acid conservation at the folate site, which implies that YgfZ is not an aminomethyltransferase but is likely a folate-dependent regulatory protein involved in one-carbon metabolism.


    Organizational Affiliation

    Center for Advanced Research in Biotechnology, 9600 Gudelsky Drive, Rockville, MD 20850, USA. teplyako@umbi.umd.edu




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
YGFZ Protein
A
328Escherichia coli (strain K12)Mutation(s): 0
Gene Names: ygfZ (yzzW)
Find proteins for P0ADE8 (Escherichia coli (strain K12))
Go to UniProtKB:  P0ADE8
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.193
  • Space Group: P 31 2 1
Unit Cell:
Length (Å)Angle (°)
a = 151.000α = 90.00
b = 151.000β = 90.00
c = 68.000γ = 120.00
Software Package:
Software NamePurpose
HKL-2000data reduction
MLPHAREphasing
SCALEPACKdata scaling
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2004-03-09
    Type: Initial release
  • Version 1.1: 2008-04-29
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
