1NR8 | pdb_00001nr8

The crystal structure of a D-Lysine-based chiral PNA-DNA duplex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.66 Å
  • R-Value Free:
    0.228 (Depositor), 0.215 (DCC)
  • R-Value Work:
    0.197 (Depositor), 0.186 (DCC)
  • R-Value Observed:
    0.214 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1NR8

This is version 4.0 of the entry. See complete history

Literature

Insights into peptide nucleic acid (PNA) structural features: The crystal structure of a D-lysine-based chiral PNA-DNA duplex

Menchise, V.De Simone, G.Tedeschi, T.Corradini, R.Sforza, S.Marchelli, R.Capasso, D.Saviano, M.Pedone, C.

(2003) Proc Natl Acad Sci U S A 100: 12021-12026

  • DOI: https://doi.org/10.1073/pnas.2034746100
  • Primary Citation Related Structures:
    1NR8

  • PubMed Abstract:

    Peptide nucleic acids (PNAs) are oligonucleotide analogues in which the sugar-phosphate backbone has been replaced by a pseudopeptide skeleton. They bind DNA and RNA with high specificity and selectivity, leading to PNA-RNA and PNA-DNA hybrids more stable than the corresponding nucleic acid complexes. The binding affinity and selectivity of PNAs for nucleic acids can be modified by the introduction of stereogenic centers (such as D-Lys-based units) into the PNA backbone. To investigate the structural features of chiral PNAs, the structure of a PNA decamer containing three D-Lys-based monomers (namely H-GpnTpnApnGpnAdlTdlCdlApnCpnTpn-NH2, in which pn represents a pseudopeptide link and dl represents a D-Lys analogue) hybridized with its complementary antiparallel DNA has been solved at a 1.66-A resolution by means of a single-wavelength anomalous diffraction experiment on a brominated derivative. The D-Lys-based chiral PNA-DNA (LPD) heteroduplex adopts the so-called P-helix conformation. From the substantial similarity between the PNA conformation in LPD and the conformations observed in other PNA structures, it can be concluded that PNAs possess intrinsic conformational preferences for the P-helix, and that their flexibility is rather restricted. The conformational rigidity of PNAs is enhanced by the presence of the chiral centers, limiting the ability of PNA strands to adopt other conformations and, ultimately, increasing the selectivity in molecular recognition.


  • Organizational Affiliation
    • Istituto di Biostrutture e Bioimmagini, Consiglio Nazionale delle Ricerche, Via Mezzocannone 6, I-80134 Naples, Italy.

Macromolecule Content

  • Total Structure Weight: 6.01 kDa
  • Atom Count: 494
  • Modeled Residue Count: 21
  • Deposited Residue Count: 21
  • Unique nucleic acid chains: 1

Macromolecules

Find similar nucleic acids by:  Sequence
Entity ID: 1
MoleculeChains LengthOrganismImage
5'-D(P*AP*GP*TP*GP*AP*TP*CP*TP*AP*C)-3'10N/A
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
H-((GPN)*(TPN)*(APN)*(GPN)*(A66)*(T66)*(C66)*(APN)*(CPN)*(TPN))-NH211N/A
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MG

Query on MG



Download:Ideal Coordinates CCD File
C [auth B]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
A66
Query on A66
B
L-PEPTIDE LINKINGC15 H24 N8 O3LYS
APN
Query on APN
B
PEPTIDE-LIKEC11 H16 N7 O3

--

C66
Query on C66
B
L-PEPTIDE LINKINGC14 H24 N6 O4

--

CPN
Query on CPN
B
PEPTIDE-LIKEC10 H16 N5 O4

--

GPN
Query on GPN
B
PEPTIDE-LIKEC11 H16 N7 O4

--

T66
Query on T66
B
L-PEPTIDE LINKINGC15 H25 N5 O5

--

TPN
Query on TPN
B
PEPTIDE-LIKEC11 H17 N4 O5

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.66 Å
  • R-Value Free:  0.228 (Depositor), 0.215 (DCC)
  • R-Value Work:  0.197 (Depositor), 0.186 (DCC)
  • R-Value Observed: 0.214 (Depositor)
Space Group: P 31
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 34.94α = 90
b = 34.94β = 90
c = 35.8γ = 120
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
SOLVEphasing
CNSrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2003-10-28
    Type: Initial release
  • Version 1.1: 2008-04-29
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 2.0: 2023-11-15
    Changes: Atomic model, Data collection, Database references, Derived calculations
  • Version 3.0: 2025-08-13
    Changes: Atomic model, Data collection, Derived calculations, Polymer sequence, Structure summary
  • Version 4.0: 2026-04-01
    Changes: Polymer sequence, Structure summary
