1N0G

Crystal Structure of A Cell Division and Cell Wall Biosynthesis Protein UPF0040 from Mycoplasma pneumoniae: Indication of A Novel Fold with A Possible New Conserved Sequence Motif


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Free: 0.283
  • R-Value Work: 0.229

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Crystal structure of a protein associated with cell division from Mycoplasma pneumoniae (GI: 13508053): a novel fold with a conserved sequence motif.

Chen, S.Jancrick, J.Yokota, H.Kim, R.Kim, S.-H.

(2004) Proteins 55: 785-791

  • DOI: 10.1002/prot.10593
  • Primary Citation of Related Structures:  1N0F, 1N0E

  • PubMed Abstract:
  • UPF0040 is a family of proteins implicated in a cellular function of bacteria cell division. There is no structure information available on protein of this family. We have determined the crystal structure of a protein from Mycoplasma pneumoniae that ...

    UPF0040 is a family of proteins implicated in a cellular function of bacteria cell division. There is no structure information available on protein of this family. We have determined the crystal structure of a protein from Mycoplasma pneumoniae that belongs to this family using X-ray crystallography. Structural homology search reveals that this protein has a novel fold with no significant similarity to any proteins of known three-dimensional structure. The crystal structures of the protein in three different crystal forms reveal that the protein exists as a ring of octamer. The conserved protein residues, including a highly conserved DXXXR motif, are examined on the basis of crystal structure.


    Organizational Affiliation

    Department of Chemistry, University of California, Berkeley, California 94720, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Protein mraZ
A, B
166Mycoplasma pneumoniae (strain ATCC 29342 / M129)Gene Names: mraZ
Find proteins for P75467 (Mycoplasma pneumoniae (strain ATCC 29342 / M129))
Go to UniProtKB:  P75467
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Free: 0.283
  • R-Value Work: 0.229
  • Space Group: P 4
Unit Cell:
Length (Å)Angle (°)
a = 101.442α = 90.00
b = 101.442β = 90.00
c = 38.193γ = 90.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
CNSrefinement
AMoREphasing
HKL-2000data reduction
HKL-2000data collection

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2003-10-21
    Type: Initial release
  • Version 1.1: 2008-04-28
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Derived calculations, Version format compliance
  • Version 1.3: 2011-11-16
    Type: Atomic model
