1MQ2

Human DNA Polymerase Beta Complexed With Gapped DNA Containing an 8-oxo-7,8-dihydro-Guanine and dAMP

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.317
  • R-Value Work: 0.257
  • R-Value Observed: 0.260

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history.


Literature

Structure of DNA Polymerase beta with the Mutagenic DNA Lesion 8-oxodeoxyguanine Reveals Structural Insights into its Coding Potential

Krahn, J.M., Beard, W.A., Miller, H., Grollman, A.P., Wilson, S.H.

(2003) Structure 11: 121-127

  • DOI: https://doi.org/10.1016/s0969-2126(02)00930-9
  • Primary Citation of Related Structures:
    1MQ2, 1MQ3

  • PubMed Abstract:

    • Oxidative damage to DNA generates 8-oxo-7,8-dihydro-2'-deoxyguanosine (8-oxodG). During DNA replication and repair synthesis, 8-oxodG can pair with cytosine or adenine. The ability to accurately replicate through this lesion depends on the DNA polymerase ...

    Oxidative damage to DNA generates 8-oxo-7,8-dihydro-2'-deoxyguanosine (8-oxodG). During DNA replication and repair synthesis, 8-oxodG can pair with cytosine or adenine. The ability to accurately replicate through this lesion depends on the DNA polymerase. We report the first structure of a polymerase with a promutagenic DNA lesion, 8-oxodG, in the confines of its active site. The modified guanine residue is in an anti conformation and forms Watson-Crick hydrogen bonds with an incoming dCTP. To accommodate the oxygen at C8, the 5'-phosphate backbone of the templating nucleotide flips 180 degrees. Thus, the flexibility of the template sugar-phosphate backbone near the polymerase active site is one parameter that influences the anti-syn equilibrium of 8-oxodG. Our results provide insights into the mechanisms employed by polymerases to select the complementary dNTP.

    Organizational Affiliation:

    Laboratory of Structural Biology, National Institute of Environmental Health Sciences, NIH, P.O. Box 12233, Research Triangle Park, NC 27709, USA.



Macromolecules

Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
DNA POLYMERASE BETAD [auth A]335Homo sapiensMutation(s): 0
Gene Names: POLB
EC: 2.7.7.7 (PDB Primary Data), 4.2.99 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P06746 (Homo sapiens)
Explore P06746
Go to UniProtKB:  P06746
PHAROS:  P06746
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP06746
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChainsLengthOrganismImage
5'-D(*CP*CP*GP*AP*CP*(8OG)P*TP*CP*GP*CP*AP*TP*CP*AP*GP*C)-3'A [auth T]16N/A
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsLengthOrganismImage
5'-D(*GP*CP*TP*GP*AP*TP*GP*CP*GP*(2DA))-3'B [auth P]10N/A
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChainsLengthOrganismImage
5'-D(P*GP*TP*CP*GP*G)-3'C [auth D]5N/A
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
DA
Query on DA
Download Ideal Coordinates CCD File
E [auth T]2'-DEOXYADENOSINE-5'-MONOPHOSPHATE
C10 H14 N5 O6 P
KHWCHTKSEGGWEX-RRKCRQDMSA-N		 Ligand Interaction
NA
Query on NA
Download Ideal Coordinates CCD File
F [auth A],
G [auth A]		SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.317
  • R-Value Work: 0.257
  • R-Value Observed: 0.260
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 55.2α = 90
b = 81β = 106.1
c = 55.6γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
CNSrefinement
CNSphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2003-01-28
    Type: Initial release
  • Version 1.1: 2008-04-28
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
