1LVY

PORCINE ELASTASE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.87 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.187
  • R-Value Observed: 0.185

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

High-pressure krypton gas and statistical heavy-atom refinement: a successful combination of tools for macromolecular structure determination.

Schiltz, M.Shepard, W.Fourme, R.Prange, T.de la Fortelle, E.Bricogne, G.

(1997) Acta Crystallogr D Biol Crystallogr 53: 78-92

  • DOI: 10.1107/S0907444996009705
  • Primary Citation of Related Structures:
    1LVY

  • PubMed Abstract:
  • The noble gas krypton is shown to bind to crystallized proteins in a similar way to xenon [Schiltz, Prangé & Fourme (1994). J. Appl. Cryst. 27, 950-960]. Preliminary tests show that the major krypton binding sites are essentially identical to those of xenon ...

    The noble gas krypton is shown to bind to crystallized proteins in a similar way to xenon [Schiltz, Prangé & Fourme (1994). J. Appl. Cryst. 27, 950-960]. Preliminary tests show that the major krypton binding sites are essentially identical to those of xenon. Noticeable substitution is achieved only at substantially higher pressures (above 50 x 10(5) Pa). As is the case for xenon, the protein complexes with krypton are highly isomorphous with the native structure so that these complexes can be used for phase determination in protein crystallography. Krypton is not as heavy as xenon, but its K-absorption edge is situated at a wavelength (0.86 A) that is readily accessible on synchrotron radiation sources. As a test case, X-ray diffraction data at the high-energy side of the K edge were collected on a crystal of porcine pancreatic elastase (molecular weight of 25.9 kDa) put under a krypton gas pressure of 56 x 10(5) Pa. The occupancy of the single Kr atom is approximately 0.5, giving isomorphous and anomalous scattering strengths of 15.2 and 1.9 e, respectively. This derivative could be used successfully for phase determination with the SIRAS method (single isomorphous replacement with anomalous scattering). After phase improvement by solvent flattening, the resulting electron-density map is of exceptionally high quality, and has a correlation coefficient of 0.85 with a map calculated from the refined native structure. Careful data collection and processing, as well as the correct statistical treatment of isomorphous and anomalous signals have proven to be crucial in the determination of this electron-density map. Heavy-atom refinement and phasing were carried out with the program SHARP, which is a fully fledged implementation of the maximum-likelihood theory for heavy-atom refinement [Bricogne (1991). Crystallographic Computing 5, edited by D. Moras, A. D. Podjarny & J. C. Thierry, pp. 257-297. Oxford: Clarendon Press]. It is concluded that the use of xenon and krypton derivatives, when they can be obtained, associated with statistical heavy-atom refinement will allow one to overcome the two major limitations of the isomorphous replacement method i.e. non-isomorphism and the problem of optimal estimation of heavy-atom parameters.


    Related Citations:
    • Structure of Native Porcine Pancreatic Elastase at 1.65 A Resolutions
      Meyer, E., Cole, G., Radhakrishnan, R., Epp, O.
      (1988) Acta Crystallogr B 44: 26
    • The Atomic Structure of Crystalline Porcine Pancreatic Elastase at 2.5 A Resolution: Comparisons with the Structure of Alpha-Chymotrypsin
      Sawyer, L., Shotton, D.M., Campbell, J.W., Wendell, P.L., Muirhead, H., Watson, H.C.
      (1978) J Mol Biol 118: 137
    • Amino-Acid Sequence of Porcine Pancreatic Elastase and its Homologies with Other Serine Proteinases
      Shotton, D.M., Hartley, B.S.
      (1970) Nature 225: 802

    Organizational Affiliation

    LURE, Bâtiment 209d, Université Paris Sud, Orsay, France. schiltz@lure.u-paris.fr



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
ELASTASEA240Sus scrofaMutation(s): 0
Gene Names: CELA1ELA1
EC: 3.4.21.36
UniProt
Find proteins for P00772 (Sus scrofa)
Explore P00772
Go to UniProtKB:  P00772
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
C [auth A]SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
CA
Query on CA

Download Ideal Coordinates CCD File
B [auth A]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.87 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.187
  • R-Value Observed: 0.185
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 51.637α = 90
b = 57.973β = 90
c = 75.32γ = 90
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling
SHARPphasing
PROLSQrefinement
CCP4data scaling

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1997-01-27
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
