1KSV

STRUCTURE OF RSUA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.210

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Structure of the 16S rRNA pseudouridine synthase RsuA bound to uracil and UMP.

Sivaraman, J.Sauve, V.Larocque, R.Stura, E.A.Schrag, J.D.Cygler, M.Matte, A.

(2002) Nat Struct Biol 9: 353-358

  • DOI: https://doi.org/10.1038/nsb788
  • Primary Citation of Related Structures:
    1KSK, 1KSL, 1KSV

  • PubMed Abstract:

    In Escherichia coli, the pseudouridine synthase RsuA catalyzes formation of pseudouridine (psi) at position 516 in 16S rRNA during assembly of the 30S ribosomal subunit. We have determined the crystal structure of RsuA bound to uracil at 2.0 A resolution and to uridine 5'-monophosphate (UMP) at 2.65 A resolution. RsuA consists of an N-terminal domain connected by an extended linker to the central and C-terminal domains. Uracil and UMP bind in a cleft between the central and C-terminal domains near the catalytic residue Asp 102. The N-terminal domain shows structural similarity to the ribosomal protein S4. Despite only 15% amino acid identity, the other two domains are structurally similar to those of the tRNA-specific psi-synthase TruA, including the position of the catalytic Asp. Our results suggest that all four families of pseudouridine synthases share the same fold of their catalytic domain(s) and uracil-binding site.


  • Organizational Affiliation

    Biotechnology Research Institute, 6100 Royalmount Avenue, Montreal, Quebec H4P 2R2, Canada.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
RIBOSOMAL SMALL SUBUNIT PSEUDOURIDINE SYNTHASE A234Escherichia coliMutation(s): 4
EC: 4.2.1.70
UniProt
Find proteins for P0AA43 (Escherichia coli (strain K12))
Explore P0AA43
Go to UniProtKB:  P0AA43
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AA43
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
U
Query on U

Download Ideal Coordinates CCD File
B [auth A]URIDINE-5'-MONOPHOSPHATE
C9 H13 N2 O9 P
DJJCXFVJDGTHFX-XVFCMESISA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.210
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.061α = 90
b = 147.58β = 90
c = 34.879γ = 90
Software Package:
Software NamePurpose
CNSrefinement
SCALEPACKdata scaling
CNSphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2002-04-24
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-10-11
    Changes: Refinement description
  • Version 1.4: 2018-01-31
    Changes: Experimental preparation
