1KEL

CATALYTIC ANTIBODY 28B4 FAB FRAGMENT COMPLEXED WITH HAPTEN (1-[N-4'-NITROBENZYL-N-4'-CARBOXYBUTYLAMINO] METHYLPHOSPHONIC ACID)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.9 Å
  • R-Value Free: 0.258
  • R-Value Work: 0.199

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Insights into antibody catalysis: structure of an oxygenation catalyst at 1.9-angstrom resolution.

Hsieh-Wilson, L.C.Schultz, P.G.Stevens, R.C.

(1996) Proc.Natl.Acad.Sci.USA 93: 5363-5367

  • Primary Citation of Related Structures:  1KEM

  • PubMed Abstract:
  • The x-ray crystal structures of the sulfide oxidase antibody 28B4 and of antibody 28B4 complexed with hapten have been solved at 2.2-angstrom and 1.9-angstrom resolution, respectively. To our knowledge, these structures are the highest resolution cat ...

    The x-ray crystal structures of the sulfide oxidase antibody 28B4 and of antibody 28B4 complexed with hapten have been solved at 2.2-angstrom and 1.9-angstrom resolution, respectively. To our knowledge, these structures are the highest resolution catalytic antibody structures to date and provide insight into the molecular mechanism of this antibody-catalyzed monooxygenation reaction. Specifically, the data suggest that entropic restriction plays a fundamental role in catalysis through the precise alignment of the thioether substrate and oxidant. The antibody active site also stabilizes developing charge on both sulfur and periodate in the transition state via cation-pi and electrostatic interactions, respectively. In addition to demonstrating that the active site of antibody 28B4 does indeed reflect the mechanistic information programmed in the aminophosphonic acid hapten, these high-resolution structures provide a basis for enhancing turnover rates through mutagenesis and improved hapten design.


    Related Citations:
    • An Efficient Antibody-Catalyzed Monooxygenation Reaction
      Hsieh, L.C.,Stephans, J.C.,Schultz, P.G.
      (1994) J.Am.Chem.Soc. 116: 2167


    Organizational Affiliation

    Department of Chemistry, University of California, Berkeley, 94720, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
28B4 FAB
L
217N/AN/A
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
28B4 FAB
H
218Mus musculusGene Names: Ighg1 (Igh-4)
Find proteins for P01868 (Mus musculus)
Go to UniProtKB:  P01868
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
AAH
Query on AAH

Download SDF File
Download CCD File
H
1-[N-4'-NITROBENZYL-N-4'-CARBOXYBUTYLAMINO]METHYLPHOSPHONIC ACID
C13 H19 N2 O7 P
RWVBLRUMXIXUAR-UHFFFAOYSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
AAHKd: 52 nM BINDINGMOAD
AAHKd: 52 nM PDBBIND
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.9 Å
  • R-Value Free: 0.258
  • R-Value Work: 0.199
  • Space Group: P 1
Unit Cell:
Length (Å)Angle (°)
a = 52.700α = 94.30
b = 58.200β = 113.80
c = 43.200γ = 78.90
Software Package:
Software NamePurpose
X-PLORmodel building
X-PLORrefinement
X-PLORphasing
DENZOdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 1996-12-07
    Type: Initial release
  • Version 1.1: 2008-03-24
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
