1K42

The Solution Structure of the CBM4-2 Carbohydrate Binding Module from a Thermostable Rhodothermus marinus Xylanase.


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 50
  • Conformers Submitted: 12
  • Selection Criteria: structures with acceptable covalent geometry,structures with the least restraint violations,structures with the lowest energy

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

The solution structure of the CBM4-2 carbohydrate binding module from a thermostable Rhodothermus marinus xylanase.

Simpson, P.J.Jamieson, S.J.Abou-Hachem, M.Karlsson, E.N.Gilbert, H.J.Holst, O.Williamson, M.P.

(2002) Biochemistry 41: 5712-5719

  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The solution structure is presented for the second family 4 carbohydrate binding module (CBM4-2) of xylanase 10A from the thermophilic bacterium Rhodothermus marinus. CBM4-2, which binds xylan tightly, has a beta-sandwich structure formed by 11 stran ...

    The solution structure is presented for the second family 4 carbohydrate binding module (CBM4-2) of xylanase 10A from the thermophilic bacterium Rhodothermus marinus. CBM4-2, which binds xylan tightly, has a beta-sandwich structure formed by 11 strands, and contains a prominent cleft. From NMR titrations, it is shown that the cleft is the binding site for xylan, and that the main amino acids interacting with xylan are Asn31, Tyr69, Glu72, Phe110, Arg115, and His146. Key liganding residues are Tyr69 and Phe110, which form stacking interactions with the sugar. It is suggested that the loops on which the rings are displayed can alter their conformation on substrate binding, which may have functional importance. Comparison both with other family 4 cellulose binding modules and with the structurally similar family 22 xylan binding module shows that the key aromatic residues are in similar positions, and that the bottom of the cleft is much more hydrophobic in the cellulose binding modules than the xylan binding proteins. It is concluded that substrate specificity is determined by a combination of ring orientation and the nature of the residues lining the bottom of the binding cleft.


    Organizational Affiliation

    Krebs Institute, Department of Molecular Biology and Biotechnology, University of Sheffield, Sheffield S10 2TN, UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Xylanase
A
168Rhodothermus marinusMutation(s): 0
Find proteins for P96988 (Rhodothermus marinus)
Go to UniProtKB:  P96988
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 50
  • Conformers Submitted: 12
  • Selection Criteria: structures with acceptable covalent geometry,structures with the least restraint violations,structures with the lowest energy
  • Olderado: 1K42 Olderado

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2002-05-29
    Type: Initial release
  • Version 1.1: 2008-04-27
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
