1JZI

Pseudomonas aeruginosa Azurin Re(phen)(CO)3(His83)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.62 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.226

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Electron tunneling in single crystals of Pseudomonas aeruginosa azurins.

Crane, B.R.Di Bilio, A.J.Winkler, J.R.Gray, H.B.

(2001) J.Am.Chem.Soc. 123: 11623-11631

  • Primary Citation of Related Structures:  1JZE, 1JZF, 1JZG, 1JZH, 1JZJ

  • PubMed Abstract:
  • Rates of reduction of Os(III), Ru(III), and Re(I) by Cu(I) in His83-modified Pseudomonas aeruginosa azurins (M-Cu distance approximately 17 A) have been measured in single crystals, where protein conformation and surface solvation are precisely defin ...

    Rates of reduction of Os(III), Ru(III), and Re(I) by Cu(I) in His83-modified Pseudomonas aeruginosa azurins (M-Cu distance approximately 17 A) have been measured in single crystals, where protein conformation and surface solvation are precisely defined by high-resolution X-ray structure determinations: 1.7(8) x 10(6) s(-1) (298 K), 1.8(8) x 10(6) s(-1) (140 K), [Ru(bpy)2(im)(3+)-]; 3.0(15) x 10(6) s(-1) (298 K), [Ru(tpy)(bpy)(3+)-]; 3.0(15) x 10(6) s(-1) (298 K), [Ru(tpy)(phen)(3+)-]; 9.0(50) x 10(2) s(-1) (298 K), [Os(bpy)2(im)(3+)-]; 4.4(20) x 10(6) s(-1) (298 K), [Re(CO)3(phen)(+)] (bpy = 2,2'-bipyridine; im = imidazole; tpy = 2,2':6',2' '-terpyridine; phen = 1,10-phenanthroline). The time constants for electron tunneling in crystals are roughly the same as those measured in solution, indicating very similar protein structures in the two states. High-resolution structures of the oxidized (1.5 A) and reduced (1.4 A) states of Ru(II)(tpy)(phen)(His83)Az establish that very small changes in copper coordination accompany reduction but reveal a shorter axial interaction between copper and the Gly45 peptide carbonyl oxygen [2.6 A for Cu(II)] than had been recognized previously. Although Ru(bpy)2(im)(His83)Az is less solvated in the crystal, the reorganization energy for Cu(I) --> Ru(III) electron transfer falls in the range (0.6-0.8 eV) determined experimentally for the reaction in solution. Our work suggests that outer-sphere protein reorganization is the dominant activation component required for electron tunneling.


    Organizational Affiliation

    Beckman Institute, California Institute of Technology, Pasadena, California 91125, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
AZURIN
A, B
128Pseudomonas aeruginosa (strain ATCC 15692 / PAO1 / 1C / PRS 101 / LMG 12228)Gene Names: azu
Find proteins for P00282 (Pseudomonas aeruginosa (strain ATCC 15692 / PAO1 / 1C / PRS 101 / LMG 12228))
Go to UniProtKB:  P00282
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CU
Query on CU

Download SDF File
Download CCD File
A, B
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
 Ligand Interaction
IME
Query on IME

Download SDF File
Download CCD File
A
TETRA(IMIDAZOLE)DIAQUACOPPER (II)
C12 H16 Cu N8 O2
QHMVDLPUUJNKGZ-UHFFFAOYSA-N
 Ligand Interaction
REP
Query on REP

Download SDF File
Download CCD File
A, B
(1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I)
C15 H8 N2 O3 Re
HRZLGVADJDWBIJ-PZNQCYOTAN
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.62 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.226
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 93.950α = 90.00
b = 50.990β = 128.10
c = 62.440γ = 90.00
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
X-PLORmodel building
CNSrefinement
X-PLORphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2001-10-17
    Type: Initial release
  • Version 1.1: 2008-04-27
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
