1JZA

Crystal Structure of Variant 2 Scorpion Toxin from Centruroides sculpturatus Ewing


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.2 Å
  • R-Value Free: 0.287
  • R-Value Work: 0.255

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Structure of variant 2 scorpion toxin from Centruroides sculpturatus Ewing.

Cook, W.J.Zell, A.Watt, D.D.Ealick, S.E.

(2002) Protein Sci. 11: 479-486

  • DOI: 10.1110/ps.39202
  • Primary Citation of Related Structures:  1JZB

  • PubMed Abstract:
  • Centruroides sculpturatus Ewing variant 2 toxin (CsE-v2) is a neurotoxin isolated from the venom of a scorpion native to the Arizona desert. The structure of CsE-v2 was solved in two different crystal forms using a combination of molecular replacemen ...

    Centruroides sculpturatus Ewing variant 2 toxin (CsE-v2) is a neurotoxin isolated from the venom of a scorpion native to the Arizona desert. The structure of CsE-v2 was solved in two different crystal forms using a combination of molecular replacement and multiple isomorphous replacement techniques. Crystals of CsE-v2 display a temperature-dependent, reversible-phase transition near room temperature. At lower temperature the space group changes from P3(2)21 to P3(1)21 with an approximate doubling of the C-axis. The small-cell structure, which has one molecule per asymmetric unit, has an R factor of 0.229 at 2.8 A resolution. The large-cell structure has two molecules per asymmetric unit and was refined at 2.2 A resolution to an R factor of 0.255. CsE-v2 is a rigid, compact structure with four intrachain disulfide bonds. The structure is similar to other long-chain beta neurotoxins, and the largest differences occur in the last six residues. The high-resolution structure of CsE-v2 corrects an error in the reported C-terminal sequence; the terminal tripeptide sequence is Ser 64-Cys 65-Ser 66 rather than Ser 64-Ser 65-Cys 66. Comparison of CsE-v2 with long-chain alpha toxins reveals four insertions and one deletion, as well as additional residues at the N and C termini. Structural alignment of alpha and beta toxins suggests that the primary distinguishing feature between the two classes is the length of the loop between the second and third strands in a three-strand beta sheet. The shorter loop in alpha toxins exposes a critical lysine side chain, whereas the longer loop in beta toxins buries the corresponding basic residue (either arginine or lysine).


    Organizational Affiliation

    Department of Pathology, University of Alabama at Birmingham, 35294, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
NEUROTOXIN 2
A, B
66Centruroides sculpturatusN/A
Find proteins for P01493 (Centruroides sculpturatus)
Go to UniProtKB:  P01493
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.2 Å
  • R-Value Free: 0.287
  • R-Value Work: 0.255
  • Space Group: P 31 2 1
Unit Cell:
Length (Å)Angle (°)
a = 48.800α = 90.00
b = 48.800β = 90.00
c = 87.200γ = 120.00
Software Package:
Software NamePurpose
X-PLORphasing
X-GENdata scaling
X-GENdata reduction
X-PLORmodel building
X-PLORrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2002-02-27
    Type: Initial release
  • Version 1.1: 2008-04-27
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2017-10-04
    Type: Refinement description
